10FT Extension Threaded Drill Rod 3ft - 20ft Length Steel Material With Heat Treatment
T51Speed MM Extension Drill Rod and MF Rod through heat treatment like Atlas
Basic Information
| Product Name | Thread Drill Rod |
| Thread | T51 |
| Diameter | 52m |
| Length | 3660mm ( 10 ft) |
| Drill Rod Type | Extension Rod |
| Order Information | Thread + Length + Diameter |
| MOQ | 5 Pieces |
| Material | High strength alloy steel bar |
| Color | Black or based on customer requirements. |
Drill rod using thread system.With wrench flats to aid in coupling/decoupling of rods for extension drilling.
For speed rod, it will produce straighter holes and at least 10% higher penetration rate in good rock conditions compared to rod and coupling sleeve combination system.
Extension Rod(MM Rod)
R32-Round32-R32 length 3 4 6 8 10 12 ft
T38 (R38) Round39-T38 (38), length 4' 6' 10' 12'ft
T45 -Round46-T45, length 10' 12' 14' 20' ft
T51 -Round52-T51, length 12' 14' 20' ft
Applications of Rock Drill Rod
• Underground mining and surface mining
• Drifting, bench and production drilling
• Granite, basalt, limestone rock etc.
Competitive Advantage
• High grade raw material
• Manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
| Product Name: | Rock Drill Rod |
| Description: |
Thread drill rod Thread drill rod Made with best quality carbon steel bar,through heat treatment like Atlas. |
| Material: | carbon steel bar |
| MOQ: | No MOQ required for testing and trial order |
| Body Type | Round shape and hexagonal type |
| Thread type | R25,R28,R32,R38,T38,T45,T51 |
| Diameter | Hex25,Hex28,Rd32,Rd38,Rd45,Rd51 |
| Type | Thread extention Rod and MF rod |
| Length |
600mm-6400mm |
T51 Drill Rod Specification
| THREADED ROCK DRILLING TOOLS – T51 | |||||||
| Drill rod | Length | Diameter | Weight | Part Number | |||
| mm | foot | mm | inch | kg | |||
|
Extension rod, T51-Round52-T51 |
3050 | 10 | 52 | 2 | 45.3 | ER52-T51-3050 | |
| Flushing hole 21.5mm | 3660 | 12 | 52 | 2 | 54.1 | ER52-T51-3660 | |
| Wrench flat 45mm | 4270 | 14 | 52 | 2 | 63.0 | ER52-T51-4270 | |
| 4880 | 16 | 52 | 2 | 71.8 | ER52-T51-4880 | ||
| 5530 | 18 1/7 | 52 | 2 | 81.2 | ER52-T51-5530 | ||
| 6095 | 20 | 52 | 2 | 89.4 | ER52-T51-6095 | ||
| 1525 | 5 | 52 | 2 | 26.2 | MF52-T51-1525 | ||
|
MF-rod, T51-Round52-T51 |
1830 | 6 | 52 | 2 | 30.6 | MF52-T51-1830 | |
| Flushing hole 21.5mm | 3050 | 10 | 52 | 2 | 48.3 | MF52-T51-3050 | |
| 3660 | 12 | 52 | 2 | 57.1 | MF52-T51-3660 | ||
| 4270 | 14 | 52 | 2 | 66.0 | MF52-T51-4270 | ||
| 4880 | 16 | 52 | 2 | 74 | MF52-T51-4880 | ||
| 5530 | 18 1/7 | 52 | 2 | 84.2 | MF52-T51-5530 | ||
| 6095 | 20 | 52 | 2 | 92.4 | MF52-T51-6095 |
||
We can design and manufacture the personalized products to meet your specical apllication.
