50.8mm Steel Ball With Ring For Impact Test 535g UL507 Test Sphere Probe
50.8mm Steel Ball With Ring For Impact Test 535g UL507 Test Sphere Probe
Standard:IEC61032 figure 5 test probe 1,IEC60335,IEC60950, IEC60598,UL507.
Application:It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 50mm or greater. It is also regarded as the steel ball for dropping impact test. It can be equipped with a lifting ring, and used for pendulum bob test after hanging with a rope. Steel balls with other diameters can be customized.
Test sample:Easily accessible enclosure live parts or mechanical parts.
Feature:Steel ball. It can be used for pendulum impact test or free fall impact test.
Parameters:
| Model | HT-I05B |
| Name | 50.8mm steel ball with ring |
| Steel ball diameter | SФ50.8 |
| Weight | 535±25g |
| Applied standard | UL507 |
Picture for reference:
More models:
HT-I05 50mm Test Sphere Probe 1
HT-I05A 50mm steel ball with ring
