Glass Marking Laser Cutter Control Board 10600nm Or 1064nm Laser Type
Glass Marking Laser Cutter Control Board 10600nm Or 1064nm Laser Type
Description:
Quick Details
Place of Origin:
China
Brand Name:
BJJCZ
Model Number:
LMCV4-DIGIT
Product name:
digital laser control board
Application:
CO2 laser marking/engraving
Wavelength:
10600/1064nm
Laser controller is the central processing part of laser marking machine, it converts the software instructions, marking content into galvanometer, laser source and auxiliary equipment understandable language, execute marking. Data inputs also collected and calculated by the laser controller then instruct the laser machine to act accordingly, this allows laser to interact with other machines, parts in industry automatic flow line.
The laser controller board and related EZCAD software is most famous product in this field. The LMCV4-DIGIT laser controll board is compatible with mainstream CO2 laser source, YAG laser source and galvanometer scanner, hardware capable to support various I/O, mark-on-fly and maximal 2 extra axis supported.
Applications:
| Model | CO2 |
| Connect Method | USB2.0 |
| Galvo control signal | Can be directly connected to a universal digital galvao |
| Number of Input Ports | 16 universal input ports |
| Number of Output Ports | 14 way TTL/ OC |
| Remark Signal | Cache content repeated engraving |
| Extended Axis | Support for 2 extension axis |
| Flight Marking | Support |
| Multi-head Carving | Support |
| Software Second Development | Support |
| Support Operating System | XP WIN7 WIN8 WIN10 32/64 Bit System |
| Built-in Encryption Chip | Support |
| Power Supply | 5V 3A |
