Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
5-10 days
Brand:
TYANSHINE
Product Description
Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Key Features:
- Ceramic SMD3535 LED, Flat Lens
- Lower thermal resistance, higher light efficiency
- Ceramic base with good heat conductivity to enlarge the lifespan
- Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
- Various options of Colours and CCT range,
- Low expansion coefficient, high air tightness
Specifications:
SMD3535 LED 10Watt class, Flat, Rectangular LED die
| Color | Vf (V) | Max. If (mA) | λd(nm) CCT(K) |
φv(lm) IF=1000mA |
CRI |
| Red | 1.9-2.6V | 2500mA | 620-625nm | 125-160lm | |
| Green | 2.7-3.5V | 2500mA | 522-532nm | 250-320lm | |
| Royal Blue | 2.8-3.6V | 2500mA | 450-460nm | 40-65lm | |
| Light Blue | 2.8-3.6V | 2500mA | 465-475nm | 80-105lm | |
| Cyan | 2.8-3.6V | 2500mA | 485-510nm | 250-320lm | |
| Lime | 2.8-3.6V | 2500mA |
4030-4280K (565-568nm) |
350-450lm | |
| PC-Amber | 2.9-3.2V | 2500mA |
1750-1900K (587-590nm) |
235-310lm | |
| Cool White | 2.8-3.4V | 2500mA |
5700-6500K 4800-5500K |
350-480lm | 70 |
| Neutral White | 2.8-3.4V | 2500mA | 3780-4300K | 260-320lm | 80 |
| Warm White | 2.7-3.4V | 2500mA | 2870-3130K | 265-305lm | 80 |
| Warm White | 2.7-3.4V | 2500mA | 2600-2800K | 250-300lm | 80 |
| Warm White | 2.7-3.4V | 2500mA | 2130-2270K | 250-300lm | / |
SMD3535 LED 12Watt class, Flat, Circular LED die
| Color | Vf (V) | Max. If (mA) | CCT(K) |
φv(lm) IF=1000mA |
LES |
| Lime | 2.9-3.2V | 4000mA |
4030-4280K (565-568nm) |
480-630lm |
Diameter 1.35mm |
| Lime | 2.9-3.2V | 4000mA |
5400-5900K (549-552nm) |
400-600lm | |
| PC-Amber | 2.9-3.2V | 4000mA |
1750-1900K (587-590nm) |
250-320lm | |
| Cool White | 2.9-3.2V | 4000mA |
6000-7000K |
185-250lm |
Applications:
Stage Lighting,
Flashlight;
Automobile Illumination
Architectural lighting
Landscape lighting
