Ceramic SMD5050 LED Multi-colour RGBLAC LED 10W Dome Lens RGBWAC 20W LED

Price Negotiable
Price: Negotiation
MOQ: 1000pcs
Delivery Time: 5-10 days
Brand: TYANSHINE
Product Description

Ceramic SMD5050 LED Multi-colour RGBLAC LED 10W Dome Lens RGBWAC 20W LED





Features:



  1. Compact Ceramic SMD5050 LEDs, multi-colour 6in1 / 5in1
  2. Lower thermal resistance, higher light efficiency
  3. Ceramic base with good heat conductivity to enlarge the lifespan
  4. Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
  5. Various colour options: RGBACL, RGBWAC / RGBLAP / RGBWAP
  6. Low expansion coefficient, high air tightness



Specifications:





10Watt SMD5050 LED 6IN1 Multi-color



Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=350mA

 CRI

RGBWAP

10Watt

 R 800 2.0-2.8 620-625nm 45-75 /
G 800 2.8-3.4 522-532nm 90-135 /
B 800 2.8-3.4 450-460nm 15-30 /
W 800 2.8-3.4 6000-7000K 105-135 70
A 800 2.8-3.4

1780-1950K

(587-590nm)

 55-80 /
Purple 600 3.0-3.6 430-440nm 1-2 /



























Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=350mA

 CRI

RGBWYP

10Watt

 R 800 2.0-2.8 620-625nm 45-75 /
G 800 2.8-3.4 522-532nm 90-135 /
B 800 2.8-3.4 450-460nm 15-30 /
W 800 2.8-3.4 6000-7000K 105-135 70
Yellow 600 2.8-3.4 589-596nm 58-75 /
Purple 600 3.0-3.6 430-440nm 1-2 /



























Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=350mA

 CRI

RGBWAC

10Watt

 R 800 2.0-2.8 620-625nm 45-75 /
G 800 2.8-3.4 522-532nm 90-135 /
B 800 2.8-3.4 450-460nm 15-30 /
W 800 2.8-3.4 6000-7000K 105-135 70
A 800 2.8-3.4

1780-1950K

(587-590nm)

 55-80 /
Cyan 700 2.9-3.5-3.6 490-495nm 40-60 /

































Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=350mA

 CRI

RGBLAC

10Watt

 R 800 2.0-2.8 620-625nm 45-75 /
G 800 2.8-3.4 522-532nm 90-135 /
B 800 2.8-3.4 450-460nm 15-30 /
L 800 2.8-3.4

5400-5900K

(549-552nm)



 135-170 70
A 800 2.8-3.4

1780-1950K

(587-590nm)

 55-80 /
Cyan 700 2.9-3.5 490-495nm 40-60 /





































20Watt SMD5050 LED 6IN1 Multi-color

Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=700mA

 CRI

RGBWAP

20Watt

 R 1000 2.0-2.6 620-625nm 100-145 /
G 1200 2.9-3.6 522-532nm 170-230 /
B 1200 2.9-3.6 450-460nm 30-45 /
W 1200 2.9-3.6 6000-7000K 185-280 70
A 1200 2.9-3.6

1780-1950K

(587-590nm)

 120-185 /
Purple 600 3.2-3.9 435-445nm 4-5 /





























Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=700mA

 CRI

RGBLYP

20Watt

 R 1000 2.0-2.6 620-625nm 100-145 /
G 1200 2.9-3.6 522-532nm 170-230 /
B 1200 2.9-3.6 450-460nm 30-45 /
L 1200 2.8-3.6

5000-5250K

(556-560nm)

 290-360 /
Yellow 800 2.3-3.0

587-597nm

 120-185 /
Purple 600 3.2-3.9 433-443nm 1.5-2.5 /































Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=700mA

 CRI

RGBLAP

20Watt

 R 1000 2.0-2.6 620-625nm 100-145 /
G 1200 2.9-3.6 522-532nm 170-230 /
B 1200 2.9-3.6 450-460nm 30-45 /
L 1200 2.8-3.6

5000-5250K

(556-560nm)

 310-380 /
A 1200 2.9-3.6

1750-1950K

(587-597nm)

 195-245 /
Purple 600 3.2-3.9 435-445nm 1.5-2.5 /

































Multi-colour Color Max.IF
(mA)		 VF(V)

λd (nm)

CCT (°K)

Lumen(lm)

If=700mA

 CRI

RGBLAC

20Watt

 R 1000 2.0-2.6 620-625nm 100-145 /
G 1200 2.9-3.6 522-532nm 170-230 /
B 1200 2.9-3.6 450-460nm 30-45 /
L 1200 2.8-3.6

5000-5250K

(556-560nm)

 200-260 /
A 1200 2.9-3.6

1750-1950K

(587-597nm)

 150-195 /
Cyan 700 2.9-3.6 485-492nm 65-80 /



































Applications:



Stage Lighting, Image Based Lighting Panel

Automotive Illumination
Architectural lighting

Landscape lighting
