Ceramic SMD5050 LED Multi-colour RGBLAC LED 10W Flat Lens RGBWW 20W LED
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
5-10 days
Brand:
TYANSHINE
Product Description
Ceramic SMD5050 LED Multi-colour RGBLAC LED 10W Flat Lens RGBWW 20W LED
Features:
- Copmact Ceramic SMD5050 LEDs,
- Lower thermal resistance, higher light efficiency
- Ceramic base with good heat conductivity to enlarge the lifespan
- Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
- Various options colour mixture, RGBLAC, RGBLAP, RGBWW
- Low expansion coefficient, high air tightness
Specifications:
20Watt SMD5050 LED 6IN1 Multi-color
| Multi-color | Color | Max.IF (mA) |
VF(V) |
λd (nm) CCT (°K) |
Lumen(lm) If=700mA |
CRI |
|
RGBLYP 20Watt |
R | 1000 | 2.0-2.8 | 620-625nm | 70-100 | / |
| G | 1200 | 2.8-3.6 | 520-530nm | 150-230 | / | |
| B | 1200 | 2.8-3.6 | 450-460nm | 25-40 | / | |
| L | 1200 | 2.9-3.5 | 5000-5250K | 270-320 | / | |
| Y | 1000 | 2.3-3.0 | 1500-1600K | 110-140 | / | |
| UV | 500 | 3.0-3.8 | 399-404nm | 490-600mW | / |
| Multi-color | Color | Max.IF (mA) |
VF(V) |
λd (nm) CCT (°K) |
Lumen(lm) If=700mA |
CRI |
|
RGBLAC 20Watt |
R | 1000 | 2.0-2.8 | 620-625nm | 70-100 | / |
| G | 1200 | 2.8-3.6 | 520-530nm | 150-230 | / | |
| B | 1200 | 2.8-3.6 | 450-460nm | 25-40 | / | |
| L | 1200 | 2.9-3.5 | 4030-4280K | 190-240 | / | |
| A | 1200 | 2.3-3.0 | 1850-1950K | 130-180 | / | |
| C | 700 | 2.9-3.5 | 490-495nm | 60-70 | / |
| Multi-color | Color | Max.IF (mA) |
VF(V) |
λd (nm) CCT (°K) |
Lumen(lm) If=700mA |
CRI |
|
RGBLWW 20Watt |
R | 1000 | 2.0-2.8 | 620-625nm | 70-100 | / |
| G | 1200 | 2.8-3.6 | 520-530nm | 150-230 | / | |
| B | 1200 | 2.8-3.6 | 450-460nm | 25-40 | / | |
| L | 1200 | 2.9-3.5 | 3900-4100K | 200-250 | / | |
| W | 1200 | 2.9-3.6 | 5600-6000K | 140-170 | 90 | |
| WW | 1000 | 2.8-3.6 | 2850-2960K | 120-150 | 90 |
20Watt SMD5050 LED 5IN1 Multi-color
| Multi-color | Color | Max.IF (mA) |
VF(V) |
λd (nm) CCT (°K) |
Lumen(lm) If=1000mA |
CRI |
|
RGBLW 20Watt |
R | 2000 | 2.0-2.8 | 630-638nm | 80-100 | / |
| G | 1800 | 2.8-3.6 | 520-530nm | 190-250 | / | |
| B | 1800 | 2.8-3.6 | 450-460nm | 30-45 | / | |
| 465-475nm | 65-85 | |||||
| L | 2200 | 2.8-3.6 | 4250-4500K | 285-360 | / | |
| WW | 1800 | 2.8-3.6 | 2850-3200K | 225-285 | 80 |
| Multi-color | Color | Max.IF (mA) |
VF(V) |
λd (nm) CCT (°K) |
Lumen(lm) If=700mA |
CRI |
|
RGBWW 20Watt |
R | 1000 | 2.0-2.8 | 620-625nm | 70-100 | / |
| G | 1200 | 2.8-3.6 | 520-530nm | 150-230 | / | |
| B | 1200 | 2.8-3.6 | 450-460nm | 25-40 | / | |
| W | 1800 | 2.9-3.6 | 5800-6400K | 180-230 | 95 | |
| WW | 1800 | 2.8-3.6 | 2670-2840K | 130-170 | 95 |
Applications:
Stage Lighting, Image Based Lighting Panel
Automotive Illumination
Architectural lighting
Landscape lighting
