Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Price:
Negotiation
MOQ:
1000pcs
Delivery Time:
5-10 days
Brand:
TYANSHINE
Product Description
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Features:
- Small size, high power Ceramic SMD Package,
- Lower thermal resistance, higher light efficiency
- Ceramic base with good heat conductivity to enlarge the lifespan
- Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
- SMD Components suitable for reflow-solidering,
- Low expansion coefficient, high air tightness
Specifications:
120Watt 4in1 RGBW
| Color | Vf (V) | Max. If (mA) | λd(nm) CCT(K) |
φv(lm) IF=1000mA |
| Red | 2.4-3.2V | 5000mA x 2 | 620-627nm | 230-290lm |
| Green | 3.2-4.0V | 5500mA x 2 | 527-532nm | 680-850lm |
| Blue | 3.0-3.8V | 6000mA | 450-455nm | 60-80lm |
| Cool White | 3.0-3.8V | 5000mA x 2 | 5700-6500K | 800-900lm |
120Watt 4in1 RGBL
| Color | Vf (V) | Max. If (mA) | λd(nm) CCT(K) |
φv(lm) IF=1000mA |
| Red | 2.4-3.2V | 5000mA x 2 | 620-627nm | 230-290lm |
| Green | 3.2-4.0V | 5500mA x 2 | 527-532nm | 680-850lm |
| Blue | 3.0-3.8V | 6000mA x 1 | 450-455nm | 60-80lm |
| Lime | 3.0-3.8V | 5000mA x 2 | 4250-4500K | 820-1000lm |
180Watt 4in1 RGBW
| Color | Vf (V) | Max. If (mA) | λd(nm) CCT(K) |
φv(lm) IF=1000mA |
| Red | 6.0-7V | 5000mA | 620-625nm | 360-500lm |
| Green | 7.5-8.5V | 5500mA | 527-532nm | 900-1200lm |
| Blue | 8.3-9.3V | 6000mA | 452-457nm | 145-185lm |
| Cool White | 8.3-9.3V | 5000mA | 5700-6500K | 1100-1450lm |
180Watt 4in1 RGBL
| Color | Vf (V) | Max. If (mA) | λd(nm) CCT(K) |
φv(lm) IF=1000mA |
| Red | 6.0-7V | 5000mA | 620-625nm | 360-500lm |
| Green | 7.5-8.5V | 5500mA | 527-532nm | 900-1200lm |
| Blue | 8.3-9.3V | 6000mA | 452-457nm | 145-185lm |
| Lime | 8.3-9.3V | 5000mA | 4150-4400K | 800-1100lm |
Applications:
Stage Lighting, Beam Wash Flood effects
Architectural lighting
Landscape lighting
