Smart Lighting 500mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW
Price:
Negotiable
MOQ:
10
Delivery Time:
Negotiable
Brand:
TYANSHINE
Product Description
Smart Lighting 400mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW
Key Features:
■ Excellent color-mixing, no color deviation, even color spot;
■ Cross-distribution of different colors, no polarized light;
■ High light quality, anti-glare
■ Fast thermal conductivity substrate, lower resistance
■ Compatible COB PKG size, easy to adapt accessories
Specifications:
| Code | Color |
Vf (V) |
If (mA) |
CRI |
CCT |
Power |
LES (mm) |
| TX-1919RGBW70C12V12-02H90 | RGBW | 36V | 500 | 90+ | 6000K | 70W |
Φ12mm |
Characteristics at If=450mA (Ta=25°C)
| Parameter | Symbol | Emitting Color |
Values | |||
| Min. | Typ. | Max. | ||||
| Luminous Flux | φv | R | 550lm | 700lm | - | |
| G | 920lm | 1160lm | - | |||
| B | 230lm | 290lm | - | |||
| W | 1020lm | 1200lm | - | |||
| Dominant Wavelength | λd | R | 620nm | 625nm | 630nm | |
| G | 522nm | 527nm | 532nm | |||
| B | 450nm | 455nm | 460nm | |||
| Colour Temperature | CCT | W | 5500K | - | 6000K | |
| Forward Voltage | Vf | R | 31V | 33V | 36V | |
| G | 33V | 36V | 39V | |||
| B | 33V | 36V | 39V | |||
| W | 33V | 36V | 39V | |||
Applications:
Entertainment lighting,
Architectural lighting
Smart lighting
Event lighting
Commercial Lighting
