Smart Lighting 400mA RGBW LED 40W COB LED LES11mm 21V LED COB RGBW
Price:
Negotiable
MOQ:
10
Delivery Time:
Negotiable
Brand:
TYANSHINE
Product Description
Smart Lighting 400mA RGBW LED 40W COB LED LES11mm 21V LED COB RGBW
Key Features:
■ Excellent color-mixing, no color deviation, even color spot;
■ Cross-distribution of different colors, no polarized light;
■ High light quality, anti-glare
■ Fast thermal conductivity substrate, lower resistance
■ Compatible COB PKG size, easy to adapt accessories
Specifications:
| Code | Color |
Vf (V) |
If (mA) |
CRI |
CCT |
Power |
LES (mm) |
| TX-1515RGBW40C11V07-20H90 | RGBW | 19-23V | 400 | 90+ | 4000K / 6500K | 40W | 11 |
Characteristics at If=400mA (Ta=25°C)
| Parameter | Symbol | Emitting Color |
Values | |||
| Min. | Typ. | Max. | ||||
| Luminous Flux | φv | R | 420lm | 490lm | - | |
| G | 500lm | 600lm | - | |||
| B | 100lm | 120lm | - | |||
| W | 500lm | 600lm | - | |||
| Dominant Wavelength | λd | R | 625nm | 630nm | 635nm | |
| G | 512nm | 517nm | 522nm | |||
| B | 445nm | 450nm | 455nm | |||
| Colour Temperature | CCT | W | 3900-4200K, 6000-6500K | |||
| Forward Voltage | Vf | R | 19V | 21V | 23V | |
| G | 19V | 21V | 23V | |||
| B | 19V | 21V | 23V | |||
| W | 19V | 21V | 23V | |||
Applications:
Entertainment lighting, Projection lights
Architectural lighting
Medical lighting
Event lighting
Stage lighting Projection
Fiber optic lighting
