Call - Touch Smart Rugged Tablets PC with Download Google Play Store
Call - Touch Smart Rugged Tablets PC with Download Google Play Store
Advantages of KT80Q Android Tablet PC:
-
Alloy body Frame
-
OEM/ODM Customization Accepted
-
Innovation: Magnetic Charging Design-16800mAh battery
-
Support 4G LTE & Dual Band WiFi
-
Octa-Core High Performance
-
OEM by FOXCONN
Specifications of KT80Q Android Tablet PC:
-
Armored Frame with Soft Rubber Protection
-
Quick Scanning from concealed side face
-
IRIS Recognition
-
Higher Hardware Configuration: A53 1.3Ghz Octa-Core Processor
-
2 cameras(The rear-13MP; The front-5MP)
-
Built in Batteries 6800mAh Double Pieces.
-
4G LTE and Dual-band WiFi module
-
Support Wireless Charging Technology with 15000mAh battery
-
Support Multiple Functional Modules Extension.
-
Support OEM/ODM service, Assembled by Foxconn
Paraments of KT80 Android Tablet PC:
Basic Info |
|
Development Environment |
|
| Operating System | Android 5.1 |
| SDK | Software Development Kit |
| Language | Java |
Fundamental Characteristics |
|
| Display | 8 inch IPS 1024*768 Multi-point touch capacitive screen |
| CPU | Octa-core 1.3Ghz ARM® Cortex-A53 |
| Memory | 2GB DDR3 RAM + 16GB Frash ROM |
| Storage | TF card max.32GB expansion |
Communications |
|
| 4G WWLAN | FDD B1B3B7 TDD B38B39B40 |
| WCDMA B1B2B5B8 | |
| EVDO BC0 GSM B2B3B5B8 |
|
| WiFi | 802.11 a/b/g/n |
| G-Sensor | LIS3DH |
| Bluetooth | v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE) |
| GPS/AGPS | Yes |
Physical Characteristics |
|
| Dimensions | 270 * 176 * 20mm |
| Weight | More 800g (includes main battery) |
| Stylus | Yes |
| Expansion Slots | 1*PSAM, 2*SIM |
| Interfaces | 1*Micro USB Connector USB2.0 OTG |
| 2*TF Card, 2*Audio Jack | |
| 1*Power Jack (Micro USB+Magnetic Charging) | |
| 1*USB Host, 2*RS232 | |
| Battery | rechargeable Li-ion battery 6800mAh*2pcs |
|
600hours standby time, Up to 6hours calling time, 8hours charging time(magnetic charging) |
|
| Camera | 13MP Back Camera+5MP Front Camera |
| Video | Support still image and video capture |
| Keypad | 12keys |
User Environment |
|
| Operating Temp. | -20°C to 50°C / -4°F to 122°F |
| Storage Temp. | -30°C to 70°C / -22°F to 158°F |
| Humidity(non-condensed) | Operating 10% to 90% / Storage 5% to 95% |
| Electrostatic discharge | ± 15 kV air discharge, ± 8 kV contact discharge |
| EMC regulation | CE |
| Protection class | IP65 |
| Drop resistance level | 1.5m all six sides |
|
|
|
Data Modules |
|
Barcode scanners (optional ) |
|
| 2D scanner | 2D Barcode Scanner (Optional 2) |
RFID readers (optional ) |
|
| LF RFID reader | 134.2khz, ISO 11784/11785, FDX-B/HDX (Optional 1) |
| 125khz (Optional 2) | |
| HF RFID reader | 13.56MHz, ISO 14443A/B, ISO 15693 |
| NFC reader | Include 13.56MHz, ISO 1443A/B |
| UHF RFID reader | 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with R2000 shipset, Long distance reader |
Biometric fingerprint (optional ) |
|
| Fingerprint | Crossmatch TCS1(With FBI, FIPS-201 ,ISO19794,ANSI,WSQ) (Optional 1) |
| Fingerprint | Other Customized fingerprint modules (Optional 2) |
Other Modules (optional ) |
|
| PSAM | ISO7816 (SIM card interface) |
| smart card reader | contact SMART card ISO7816 compliant |
| Far Infrared Meter Reading | IEC62056-21 (IEC1107) communication protocol |
| Retina recognition | The recognition distance is less than 20cm |
| Infrared meter reading | IEC62056-21(IEC1107) communication protocol |
| Magnetic bracket | Apply to car or desktop fixation |
| Wrist strap | 360 degree rotation |
| Stylus | Capacitance touch pen |
| IRIS | The recognition distance is less than 20cm |
| Customization | MSR |
| Other customized modules | |
