SAE J524 Low Carbon Cold Formed Seamless Steel Tube Hollow For Automotive
SAE J524 A is a specification for seamless, low carbon steel tubes used for automotive applications. These tubes are cold drawn and are used in a variety of applications, including hydraulic lines, fuel lines, and oil lines. The tubes are also used in applications where a high degree of precision is required.
Material
The material used in the manufacturing of SAE J524 A tubes is low carbon steel. This type of steel is commonly used in the automotive industry due to its strength and durability. Low carbon steel is also easy to work with, making it an ideal choice for cold forming.
Specification
The SAE J524 A specification covers seamless, low carbon steel tubes with an inside diameter of 3/16 inch to 3-1/2 inch. The tubes are manufactured using a cold drawn process, which ensures a high degree of precision and consistency in the dimensions of the tube.
Chemical Composition
The chemical composition of the SAE J524 A steel tube is as follows:
| Element | Composition (% by weight) |
|---|---|
| Carbon | 0.18 max |
| Manganese | 0.30 to 0.60 |
| Phosphorus | 0.040 max |
| Sulfur | 0.050 max |
Mechanical Properties
The mechanical properties of the SAE J524 A steel tube are as follows:
| Property | Value |
|---|---|
| Tensile Strength | 45,000 psi (min) |
| Yield Strength | 25,000 psi (min) |
| Elongation | 35% (min) |
| Hardness | HRB 60 (max) |
Steel Grade
The steel grade used in the SAE J524 A specification is 1010.
Application
SAE J524 A tubes are commonly used in automotive applications, including hydraulic lines, fuel lines, and oil lines. These tubes are also used in applications where a high degree of precision is required, such as in the manufacturing of precision instruments and equipment.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
