Seamless Precision Steel Tube Round Cold Drawn Tube GB/T 3087 For Boilers
Seamless Steel Tubes Round Cold Drawn Precision Steel GB/T 3087 Tube For Boilers
Material
The material used for the seamless steel tubes round cold drawn precision steel GB/T 3087 tube for boilers is high-quality carbon structural steel.
Specification
The specification of the seamless steel tubes is governed by GB/T 3087, which outlines the technical requirements for seamless steel tubes used in boilers.
Chemical Composition
The chemical composition of the seamless steel tubes should adhere to the following requirements:
| Element | Composition Range (%) |
|---|---|
| Carbon (C) | 0.07-0.13 |
| Silicon (Si) | 0.17-0.37 |
| Manganese (Mn) | 0.35-0.65 |
| Phosphorus (P) | ≤0.035 |
| Sulfur (S) | ≤0.035 |
Mechanical Properties
The mechanical properties of the seamless steel tubes should meet the specified values as outlined in GB/T 3087. The table below presents the required mechanical properties:
| Property | Minimum Value |
|---|---|
| Tensile Strength | 410 MPa |
| Yield Strength | 245 MPa |
| Elongation | ≥25% |
| Hardness | ≤197 HB |
| Impact Test | No fracture, ≥27 J/cm² |
Steel Grade
The steel grade used for the seamless steel tubes is determined based on the chemical composition and mechanical properties. The specific steel grade for GB/T 3087 tube for boilers is as follows:
- Grade: 10
- Designation: 10# (Ten Number)
Application
The seamless steel tubes round cold drawn precision steel GB/T 3087 tube is primarily used in boilers for various applications, including but not limited to:
- Power generation
- Industrial heating systems
- Heat exchangers
- High-pressure steam pipelines
- Superheaters and reheaters
