Welded En10305-2 Cold Drawn Carbon Steel Tubes Q345 For Auto Refrigeration
Welded Cold Drawn Carbon Steel Tubes EN10305-2 For Auto Refrigeration
Material
The material used for the welded cold drawn carbon steel tubes conforming to EN10305-2 for auto refrigeration is carbon steel.
Specification
The specification for the welded cold drawn carbon steel tubes EN10305-2 for auto refrigeration is as follows:
- Standard: EN10305-2
- Type: Welded
- Shape: Round
- Size Range: Customizable
- Length: Customizable
Chemical Composition
The chemical composition of the welded cold drawn carbon steel tubes EN10305-2 for auto refrigeration may vary slightly depending on the specific grade. However, the typical chemical composition is as follows:
| Element | Percentage Range |
| Carbon (C) | 0.17 - 0.22% |
| Silicon (Si) | 0.10 - 0.35% |
| Manganese (Mn) | 0.40 - 0.80% |
| Phosphorus (P) | 0.035% max |
| Sulfur (S) | 0.035% max |
Mechanical Properties
The mechanical properties of the welded cold drawn carbon steel tubes EN10305-2 for auto refrigeration are crucial for ensuring their performance. The typical mechanical properties are as follows:
| Property | Value |
| Tensile Strength | 420 - 580 MPa |
| Yield Strength | 250 - 350 MPa |
| Elongation | 15 - 25% |
| Hardness (HB) | 120 - 180 |
| Impact Energy (J) | 27 min |
Steel Grade
The steel grade used for the welded cold drawn carbon steel tubes EN10305-2 for auto refrigeration may vary depending on the specific requirements. However, commonly used steel grades include:
- E235
- E355
- E410
Application
The welded cold drawn carbon steel tubes EN10305-2 are specifically designed for use in auto refrigeration systems. These tubes are widely used in the automotive industry for applications such as refrigerant transfer, cooling systems, and air conditioning. Their excellent dimensional accuracy, high strength, and corrosion resistance make them suitable for demanding refrigeration environments.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
