YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well
YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well
Table of Contents
- Material
- Specification
- Key Features
- Chemical Composition
- Mechanical Properties
- Steel Grade
- Application
- Possible Alternative Grades
Material
| Material Type | Welded Steel |
|---|---|
| Surface Treatment | Galvanized |
| Manufacturing Process | Electric Welding |
| Application | Water Pump of Deep Well |
Specification
| Diameter Range (mm) | 21.3 - 219.1 |
|---|---|
| Wall Thickness (mm) | 1.6 - 7.0 |
| Length (m) | Customizable |
| Standard | YB/T 4028 |
| Available Grades | Q195, Q215, Q235 |
Key Features
- Suitable for use in deep well water pumps.
- High-quality welded steel construction.
- Corrosion-resistant galvanized surface.
- Versatile size range for various applications.
Chemical Composition
| Element | C (%) | Mn (%) | Si (%) | P (%) | S (%) |
|---|---|---|---|---|---|
| Composition | 0.12 | 0.30 | 0.30 | 0.045 | 0.045 |
Mechanical Properties
| Property | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| Mechanical Properties (Q195) | 315-430 | 195 | 33 |
| Mechanical Properties (Q215) | 335-450 | 215 | 27 |
| Mechanical Properties (Q235) | 375-500 | 235 | 25 |
Steel Grade
- Q195: A low-carbon steel grade with good ductility and weldability, suitable for various applications.
- Q215: A medium-carbon steel grade with improved strength, often used for structural purposes.
- Q235: A high-strength steel grade, suitable for load-bearing applications.
Application
The YB/T 4028 Welded Steel Tube with straight seam electric welding and a galvanized surface is specifically designed for use in water pumps for deep wells. Its reliable construction and corrosion-resistant properties make it an ideal choice for this demanding application.
Possible Alternative Grades
If the specified grade is not available or other requirements are needed, you may consider alternative steel grades such as:
- Q195: Suitable for general applications with lower strength requirements.
- Q215: Offers improved strength compared to Q195 and is often used for structural purposes.
- Q235: Provides higher strength and is ideal for load-bearing components.
These alternative grades offer flexibility to meet specific project needs and budget constraints.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
