ASTM B163 Nickel 200 Seamless Tube Nickel Alloy Tube For Seawater Heat Exchanger
ASTM B163 Nickel 200 Seamless Tube Nickel Alloy Tube For Seawater Heat Exchanger
Material, Specification, Key Features
ASTM B163 Nickel 200 Seamless Tube is a high-quality nickel alloy tube specifically designed for seawater heat exchangers. This seamless tube is built to withstand corrosive environments and high temperatures, making it an ideal choice for critical applications in marine industries.
Key Features:
- Corrosion resistance in seawater
- High thermal conductivity
- Excellent mechanical properties
- Superior weldability
Specification:
- ASTM B163
- Material: Nickel 200
- Type: Seamless Tube
- Application: Seawater Heat Exchanger
Chemical Composition
The chemical composition of ASTM B163 Nickel 200 Seamless Tube is essential in determining its performance and suitability for various applications. The following table outlines the chemical composition of Nickel 200:
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | 99.0 min |
| Iron (Fe) | 0.40 max |
| Manganese | 0.35 max |
| Carbon (C) | 0.15 max |
| Silicon (Si) | 0.35 max |
| Copper (Cu) | 0.25 max |
| Sulfur (S) | 0.01 max |
Mechanical Properties
The mechanical properties of ASTM B163 Nickel 200 Seamless Tube are crucial for ensuring its strength and durability under different operating conditions. Here are the typical mechanical properties:
| Property | Value |
|---|---|
| Tensile Strength | 39 KSI (270 MPa) |
| Yield Strength | 15 KSI (105 MPa) |
| Elongation at Break | 40% |
| Hardness (Brinell) | HRB 48 max |
Steel Grade and Application
Steel Grade: Nickel 200
Application: ASTM B163 Nickel 200 Seamless Tubes are commonly used in seawater heat exchangers, desalination plants, marine applications, and chemical processing industries where resistance to corrosion, high thermal conductivity, and reliability are crucial requirements.
Possible Alternative Grades
While Nickel 200 offers exceptional performance, there are alternative nickel alloys that can be considered based on specific application requirements. Some possible alternative grades include Nickel 201, Monel 400, Inconel 625, and Hastelloy C276. Each of these grades has its unique properties and benefits suitable for diverse industrial applications.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
