ASTM A511 MT316 Seamless Stainless Steel Mechanical Tubing
ASTM A511 MT302 MT303 MT303Se MT304 MT316 Stainless Steel Tube: Seamless Stainless Steel Mechanical Tubing
Introduction
Stainless steel tubes are widely used in various industries due to their excellent corrosion resistance, high strength, and durability. ASTM A511 MT302, MT303, MT303Se, MT304, and MT316 are seamless stainless steel mechanical tubing grades that offer exceptional performance in demanding applications. This article provides an overview of these grades, including their material composition, key features, mechanical properties, applications, and possible alternative grades.
Material and Specification
ASTM A511 is the standard specification for seamless stainless steel mechanical tubing. It covers various grades, including MT302, MT303, MT303Se, MT304, and MT316. These grades are specifically designed for mechanical applications where high strength and corrosion resistance are required.
Key Features
- Corrosion Resistance: Stainless steel grades in the A511 specification exhibit excellent resistance to corrosion, making them suitable for use in harsh environments.
- High Strength: The mechanical tubing grades offer high tensile strength, allowing them to withstand heavy loads and stresses.
- Seamless Construction: The seamless manufacturing process ensures uniformity and eliminates the risk of weak points or leaks.
- Versatility: These stainless steel grades can be easily fabricated, welded, and machined, providing flexibility in various applications.
Chemical Composition
| Grade | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) | Silicon (Si) | Chromium (Cr) | Nickel (Ni) | Molybdenum (Mo) |
|---|---|---|---|---|---|---|---|---|
| MT302 | 0.15 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.0-19.0 | 8.0-10.0 | - |
| MT303 | 0.15 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.0-19.0 | 8.0-10.0 | - |
| MT303Se | 0.15 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.0-19.0 | 8.0-10.0 | 0.15-0.35 |
| MT304 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0-20.0 | 8.0-11.0 | - |
| MT316 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 |
Mechanical Properties
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HRB) |
|---|---|---|---|---|
| MT302 | 620 min | 310 min | 30 min | 90 max |
| MT303 | 620 min | 310 min | 30 min | 90 max |
| MT303Se | 620 min | 310 min | 30 min | 90 max |
| MT304 | 515 min | 205 min | 35 min | 90 max |
| MT316 | 515 min | 205 min | 35 min | 90 max |
Steel Grade
The steel grades covered by ASTM A511 for seamless stainless steel mechanical tubing are MT302, MT303, MT303Se, MT304, and MT316.
Application
ASTM A511 MT302, MT303, MT303Se, MT304, and MT316 stainless steel tubes find applications in various industries, including:
- Automotive: Exhaust systems, structural components, and fuel lines.
- Aerospace: Hydraulic systems, instrumentation, and structural components.
- Chemical Processing: Heat exchangers, pressure vessels, and piping systems.
- Oil and Gas: Downhole tools, wellhead equipment, and subsea components.
- Mechanical Engineering: Shafts, gears, and precision components.
Possible Alternative Grades
Depending on the specific requirements of an application, alternative stainless steel grades that can be considered include:
- MT301: Offers improved corrosion resistance compared to MT302 and MT303.
- MT321: Provides enhanced resistance to high-temperature environments.
- MT347: Suitable for applications requiring resistance to intergranular corrosion.
- MT316L: Offers superior corrosion resistance and is commonly used in highly corrosive environments.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
