ASTM A866 4140 Seamless Steel Tube Medium Carbon Anti-Friction Bearing Steel For Auto
ASTM A866 1552 4130 4140 4150 5140 Seamless Steel Tube: Medium Carbon Anti-Friction Bearing Steel For Auto
Introduction
ASTM A866 1552 4130 4140 4150 5140 Seamless Steel Tube is a type of medium carbon anti-friction bearing steel widely used in the automotive industry. This article will provide an overview of the material, its specifications, key features, chemical composition, mechanical properties, steel grades, applications, and possible alternative grades.
Material and Specification
ASTM A866 1552 4130 4140 4150 5140 Seamless Steel Tube is manufactured according to the ASTM A866 standard. This specification outlines the requirements for medium carbon anti-friction bearing steel tubes used in automotive applications. The seamless tube ensures excellent dimensional accuracy and surface finish.
Key Features
- Medium carbon content: Provides a balance between strength and ductility, making it suitable for bearing applications.
- Anti-friction properties: Offers low friction and wear resistance, ensuring smooth operation and extended service life.
- Seamless construction: Enhances the tube's structural integrity and eliminates the risk of leakage or failure.
- High machinability: Allows for easy shaping, forming, and machining, facilitating the manufacturing process.
Chemical Composition
| Element | ASTM A866 1552 | ASTM A866 4130 | ASTM A866 4140 | ASTM A866 4150 | ASTM A866 5140 |
|---|---|---|---|---|---|
| Carbon (C) | 0.50-0.60% | 0.28-0.33% | 0.38-0.43% | 0.48-0.53% | 0.38-0.43% |
| Manganese (Mn) | 0.70-0.90% | 0.40-0.60% | 0.75-1.00% | 0.75-1.00% | 0.70-0.90% |
| Silicon (Si) | 0.15-0.35% | 0.15-0.35% | 0.15-0.35% | 0.15-0.35% | 0.15-0.35% |
| Chromium (Cr) | - | 0.80-1.10% | 0.80-1.10% | 0.80-1.10% | 0.70-0.90% |
| Nickel (Ni) | - | - | 0.15-0.25% | 0.15-0.25% | - |
| Molybdenum (Mo) | - | 0.15-0.25% | 0.15-0.25% | 0.15-0.25% | - |
Mechanical Properties
| Property | ASTM A866 1552 | ASTM A866 4130 | ASTM A866 4140 | ASTM A866 4150 | ASTM A866 5140 |
|---|---|---|---|---|---|
| Tensile Strength | 700-900 MPa | 560-760 MPa | 670-930 MPa | 780-1030 MPa | 700-900 MPa |
| Yield Strength | 550-750 MPa | 460-630 MPa | 590-800 MPa | 690-930 MPa | 620-820 MPa |
| Elongation | 15-20% | 20-25% | 15-20% | 15-20% | 15-20% |
| Hardness (HB) | 180-220 | 170-210 | 190-240 | 200-250 | 180-220 |
Steel Grade
ASTM A866 1552 4130 4140 4150 5140 Seamless Steel Tube falls under the medium carbon anti-friction bearing steel category. The steel grades within this specification include:
- ASTM A866 1552
- ASTM A866 4130
- ASTM A866 4140
- ASTM A866 4150
- ASTM A866 5140
Application
This seamless steel tube is primarily used in the automotive industry for various applications, including:
- Bearings: Used in the manufacturing of automotive bearings, ensuring smooth and reliable operation.
- Shafts: Suitable for shafts requiring high strength, wear resistance, and dimensional accuracy.
- Gears: Used in gear systems where durability and anti-friction properties are crucial.
- Automotive components: Utilized in the production of various automotive components, such as axles, spindles, and crankshafts.
Possible Alternative Grades
While ASTM A866 1552 4130 4140 4150 5140 Seamless Steel Tube is a widely used material, there are alternative grades available for specific requirements. Some possible alternative grades include:
- AISI 52100: A high carbon chromium alloy steel known for its excellent wear resistance and high hardness.
- AISI 8620: A low carbon nickel-chromium-molybdenum alloy steel with good strength and toughness properties.
- AISI 9310: A low alloy steel with high hardenability, suitable for applications requiring high fatigue strength.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
