ASTM A501 Gr.A Gr.B Seamless Carbon Steel Tube for Construction
ASTM A501 Gr.A Gr.B Hot Formed Structural Tubing Seamless Carbon Steel Tube for Construction
Introduction
ASTM A501 is a specification that covers hot-formed structural tubing made from carbon steel. This type of tubing is widely used in construction and structural applications due to its strength and durability. The specification includes two grades: Gr.A and Gr.B, each with distinct mechanical properties and chemical compositions.
Material
The material used in ASTM A501 tubing is carbon steel, which is known for its excellent strength-to-weight ratio and versatility in various construction applications.
Specification
ASTM A501 outlines the requirements for hot-formed structural tubing, including dimensions, tolerances, and mechanical properties. The tubing is typically produced in round, square, or rectangular shapes.
Key Features
- High Strength: Provides excellent load-bearing capabilities.
- Versatility: Suitable for various structural applications.
- Seamless Design: Ensures uniform strength and eliminates weak points.
- Hot Forming Process: Enhances mechanical properties and allows for complex shapes.
Chemical Composition
| Element | Gr.A (%) | Gr.B (%) |
|---|---|---|
| Carbon (C) | 0.26 max | 0.26 max |
| Manganese (Mn) | 0.60-0.90 | 0.60-0.90 |
| Phosphorus (P) | 0.04 max | 0.04 max |
| Sulfur (S) | 0.05 max | 0.05 max |
| Silicon (Si) | 0.10-0.40 | 0.10-0.40 |
Mechanical Properties
| Property | Gr.A | Gr.B |
|---|---|---|
| Yield Strength (ksi) | 35 min | 42 min |
| Tensile Strength (ksi) | 58-70 | 58-75 |
| Elongation (%) | 20 min | 20 min |
| Hardness (Rockwell) | B70 max | B70 max |
Steel Grade
- Gr.A: Lower yield strength, suitable for less demanding applications.
- Gr.B: Higher yield strength, ideal for more demanding structural applications.
Application
ASTM A501 structural tubing is commonly used in:
- Building frames
- Bridges
- Towers
- Heavy equipment
- Agricultural structures
Possible Alternative Grades
- ASTM A500: Another specification for cold-formed structural tubing.
- ASTM A53: Standard specification for pipe, which can be used in similar applications.
- ASTM A252: Specification for welded and seamless steel pipe piles.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
