GB/T 21833.3 S22253 Duplex Stainless Steel Pipe Seamless Austenitic Stainless Steel Tubes For Oil
GB/T 21833.3 S22253 S22053 S25203 S22553 S22583 Duplex Stainless Steel Pipe Seamless Austenitic Stainless Steel Tubes For Oil
Material
Duplex stainless steels are a family of stainless steels that contain a mixture of austenitic and ferritic phases. The grades specified in GB/T 21833.3 are designed to provide excellent corrosion resistance, high strength, and good weldability, making them suitable for various applications, particularly in the oil and gas industry.
Specification
The GB/T 21833.3 standard outlines the requirements for seamless duplex stainless steel pipes and tubes. These specifications ensure that the materials meet the necessary mechanical and chemical properties for their intended applications.
Key Features
- Corrosion Resistance: Excellent resistance to pitting and crevice corrosion.
- High Strength: Superior mechanical properties compared to standard austenitic stainless steels.
- Weldability: Good weldability with proper techniques.
- Low Thermal Expansion: Reduced thermal expansion compared to other stainless steels.
- Versatility: Suitable for various environments, including high-pressure and high-temperature applications.
Chemical Composition
| Grade | C (%) | Cr (%) | Ni (%) | Mo (%) | N (%) | Fe (%) |
|---|---|---|---|---|---|---|
| S22253 | ≤0.03 | 21.0-23.0 | 4.5-6.5 | 2.5-3.5 | 0.1-0.2 | Bal. |
| S22053 | ≤0.03 | 19.0-22.0 | 4.5-6.5 | 3.0-5.0 | 0.1-0.2 | Bal. |
| S25203 | ≤0.03 | 20.0-22.0 | 4.5-6.5 | 3.0-5.0 | 0.1-0.2 | Bal. |
| S22553 | ≤0.03 | 20.0-22.0 | 4.5-6.5 | 3.0-5.0 | 0.1-0.2 | Bal. |
| S22583 | ≤0.03 | 20.0-22.0 | 4.5-6.5 | 3.0-5.0 | 0.1-0.2 | Bal. |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness (HB) |
|---|---|---|---|---|
| S22253 | ≥450 | ≥620 | ≥25 | ≤320 |
| S22053 | ≥450 | ≥620 | ≥25 | ≤320 |
| S25203 | ≥450 | ≥620 | ≥25 | ≤320 |
| S22553 | ≥450 | ≥620 | ≥25 | ≤320 |
| S22583 | ≥450 | ≥620 | ≥25 | ≤320 |
Steel Grade
The steel grades specified in GB/T 21833.3 include:
- S22253
- S22053
- S25203
- S22553
- S22583
Application
Duplex stainless steel pipes and tubes are widely used in various applications, particularly in the oil and gas industry. Common applications include:
- Oil and gas exploration and production
- Chemical processing
- Marine environments
- Desalination plants
- Heat exchangers
Possible Alternative Grades
While the specified grades are optimal for many applications, alternative grades may also be considered based on specific requirements:
- S31803: A widely used duplex stainless steel with similar properties.
- S32750: A super duplex stainless steel offering enhanced corrosion resistance and strength.
- S304: A standard austenitic stainless steel for less demanding applications.
