ASTM A334 Gr6 Carbon Steel Seamless Tubes with Low Temperature Performance and Cold Drawn Precision
ASTM A334 Grade 6 Carbon Steel Seamless Tubes
Material Description
ASTM A334 Grade 6 carbon steel seamless tubes are engineered low-temperature service pipes manufactured from medium carbon steel with controlled chemistry and mechanical properties to ensure reliability in sub-zero environments. They are available as seamless and welded tubes designed for pressure, fluid, and structural duties where high toughness and impact resistance at low temperatures are essential.
Specifications
-
Standard: ASTM A334/A334M – Standard Specification for Seamless and Welded Carbon and Alloy-Steel Tubes for Low-Temperature Service
-
Grade: 6
-
Form: Seamless (hot finished or cold drawn)
-
Diameter & Wall: Typically 1/2″ to 24″ OD with multiple schedule thickness options (Schedule 10 to 160 and others)
-
Length: Standard random lengths or custom lengths up to approximately 27 m
Key Characteristics
-
Low-Temperature Performance: Designed for service in sub-zero and cryogenic environments without loss of toughness
-
Mechanical Strength: Balanced tensile strength, yield strength, and ductility suitable for pressure and thermal cycling
-
Impact Toughness: Mandatory notch-bar impact testing to ensure resistance to brittle fracture at low temperatures
-
Weldability & Fabrication: Good weldability and formability with low risk of cracking
Why Choose ASTM A334 Gr 6 Tubes
Reliable Low-Temperature Service
ASTM A334 Gr 6 tubes maintain structural integrity and toughness in freezing environments such as LNG systems, cryogenic plants, and cold-region pipelines.
Standards Compliance
Manufactured strictly in accordance with ASTM A334/A334M requirements and commonly supplied with additional testing and inspection certificates.
Broad Industrial Acceptance
Widely used in power generation, petrochemical processing, refineries, and heat-exchange systems where low-temperature reliability is critical.
Optimized Chemical and Mechanical Balance
Grade 6 offers a proven balance of strength, ductility, and impact resistance, reducing operational risk and extending service life.
Chemical Composition Comparison
| Grade | C (max) | Si (min) | Mn | P (max) | S (max) |
|---|---|---|---|---|---|
| ASTM A334 Gr 1 | ≤ 0.30 | ≥ 0.10 | 0.40 – 1.06 | ≤ 0.025 | ≤ 0.025 |
| ASTM A334 Gr 3 | ≤ 0.19 | ≥ 0.10 | 0.31 – 0.64 | ≤ 0.050 | ≤ 0.050 |
| ASTM A334 Gr 6 | ≤ 0.30 | ≥ 0.10 | 0.29 – 1.06 | ≤ 0.025 | ≤ 0.025 |
| ASTM A334 Gr 7 | ≤ 0.19 | ≥ 0.13 | ≤ 0.90 | ≤ 0.040 | ≤ 0.050 |
| ASTM A334 Gr 8 | ≤ 0.18 | ≥ 0.13 | ≤ 0.90 | ≤ 0.045 | ≤ 0.045 |
Mechanical Properties Comparison
| Grade | Tensile Strength (MPa, min) | Yield Strength (MPa, min) | Elongation (%) |
|---|---|---|---|
| ASTM A334 Gr 1 | ≥ 380 | ≥ 205 | ≥ 30 |
| ASTM A334 Gr 3 | ≥ 450 | ≥ 240 | ≈ 30 |
| ASTM A334 Gr 6 | ≥ 415 | ≥ 240 | ≥ 30 |
| ASTM A334 Gr 7 | ≥ 450 | ≥ 240 | ≈ 30 |
| ASTM A334 Gr 8 | ≥ 520 | ≥ 240 | ≈ 30 |
Applicable Standards
-
ASTM A334/A334M – Carbon and alloy steel tubes for low-temperature service
-
ASME SA334 – Equivalent specification under ASME Boiler and Pressure Vessel Code
-
ASTM A370 – Mechanical testing
-
ASTM E23 – Charpy impact testing
Application Fields
ASTM A334 Grade 6 seamless tubes are used in applications requiring dependable performance at low temperatures:
Oil & Gas
-
Cryogenic fluid transfer pipelines
-
Low-temperature gathering and transmission lines
-
Process piping in cold climates
Petrochemical & Refining
-
Heat exchangers and condensers
-
Pressure piping and vessels
Power & Energy
-
Cryogenic power generation systems
-
Refrigeration and cooling circuits
Industrial Equipment
-
Structural and piping components exposed to low-temperature environments
-
Chemical processing systems operating under cold conditions
