DIN 2440 2441&EN10255 S195T Welding / Threading Non - Alloy Steel Tubes

Price Negotiable

Price: USD600-900 per ton

MOQ: 5MT

Delivery Time: 30~40days

Brand: Torich

Product Description

DIN 2440 2441&EN10255 S195T Non-Alloy Steel Tubes , Structural Steel Pipe

DIN 2440 2441&EN10255 Non-alloy steel tubes,suitable for welding and threading

Applications: for converyance of fuilds as well as for other applications

Size range: O.D.:6-350mm W.T.:1-30mm L:below 12000mm

Manufacture: The tbes are manufactured by seamless or longintudinally welding process.

Chemical composition:

Note: Special steel grade is also available, according to customer request.

Mechanical properties:

Dimensions,diameter toerance and mass per unit tength:

Specified outside diamerters D (mm)	Threade Size R	Outside diameter		H Heavy series			M Medium series
		Outside diameter		Wall Thickness T (mm)	Mass per unit Length of bare tube		Wall Thickness T (mm)	Mass per unit Length of bare tube
		Max (mm)	Min (mm)		Mass per unit Length of bare tube			Mass per unit Length of bare tube
		Max (mm)	Min (mm)		Plain end (kg/m)	Socketed (kg/m)		Plain end (kg/m)	Threade and socketed (kg/m)
10.2	1/8	10.6	9.8	2.6	0.487	0.490	2.0	0.404	0.407
13.5	1/4	14.0	13.2	2.9	0.765	0.769	2.3	0.641	0.645
17.2	3/8	17.5	16.7	2.9	1.02	1.03	2.3	0.839	0.845
21.3	1/2	21.8	21.0	3.2	1.44	1.45	2.6	1.21	1.22
26.9	3/4	27.3	26.5	3.2	1.87	1.88	2.6	1.56	1.57
33.7	1	34.2	33.3	4.0	2.93	2.95	3.2	2.41	2.43
42.4	11/4	42.9	42.0	4.0	3.79	3.82	3.2	3.10	3.13
48.3	11/2	48.8	47.9	4.0	4.37	4.41	3.2	3.56	3.60
60.3	2	60.8	59.7	4.5	6.19	6.26	3.6	5.03	5.10
76.1	21/2	76.6	75.3	4.5	7.93	8.05	3.6	6.42	6.54
88.9	3	89.5	88.0	5.0	10.3	10.5	4.0	8.36	8.53
114.3	4	115.0	113.1	5.4	14.5	14.8	4.5	12.2	12.5
139.7	5	140.8	138.5	5.4	17.9	18.4	5.0	16.6	17.1
165.1	6	166.5	163.9	5.4	21.3	21.9	5.0	19.8	20.4
