Precision Steel Tubes GOST9567 10 20 35 45 40X 30ХГСА Alloy Steel Tubes
GOST9567 10 20 35 45 40X 30ХГСА Steel Tubes-Precision Steel Tubes
GOST9567 Precision steel tubes
TORICH is specialized in manufacturing cold drawn precision steel tube according to technical standard of GOST9567.
precision carbon steel tube is usually manufactured from round billet to hollow tubes, then after several cold drawn process to the final diemenion with target size tolerances and mechanical properties.
Applications of carbon steel precision tube:
Automobile, Machinery Engineering, Autoparts etc.
Size range of cold-drawn precision seamless steel tube:
O.D.:6-168mm W.T.:1-15mm L:max12000mm
Chemical Composition(%,max) for carbon steel precision tube:
| Steel Grade | C | Si | Mn | Cr | Ni | Mo | S | P | Cu |
| 10 | 0.07-0.14 | 0.17-0.37 | 0.35-0.65 | 0.15 | 0.3 | - | - | - | - |
| 20 | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | 0.25 | 0.25 | - | 0.03 | 0.025 | 0.3 |
| 35 | 0.32-0.40 | 0.17-0.37 | 0.50-0.80 | 0.25 | 0.3 | - | 0.04 | 0.035 | 0.3 |
| 45 | 0.42--0.45 | 0.17-0.37 | 0.50-0.80 | 0.25 | - | - | - | - | - |
| 40X | 0.36-0.44 | 0.17-0.37 | 0.50-0.80 | 0.80-1.10 | 0.3 | - | 0.035 | 0.035 | 0.3 |
| 30ХГСА | 0.28-0.34 | 0.90-1.20 | 0.80-1.10 | 0.80-1.10 | 0.3 | - | 0.005 | 0.025 | - |
Mechanical Properties:
| Steel Grade | Tensile Strength, N/mm2 (min) | Yield Strength, N/mm 2 (min) | Elongation, %(min) |
| 10 | 343 | 206 | 24 |
| 20 | 412 | 245 | 21 |
| 35 | 510 | 294 | 17 |
| 45 | 589 | 323 | 14 |
| 40X | 618 | - | 14 |
| 30ХГСА | 491 | - | 18 |
Production and Quality Inspection:
