4.76 X0.5Welded Low-Carbon Steel Tubing SAE J 526 UNS G10080 and UNS G10100
Price:
2USD-3USD/kg
MOQ:
3 tons
Delivery Time:
4-5weeks days
Brand:
Torich
Product Description
4.76 X0.5Welded Low-Carbon Steel Tubing SAE J 526 UNS G10080 and UNS G10100
Electric welded single wall steel tube is used is used for automobiles and refrigerator industries.
Most product features are quite similar to double wall tube.
Technical specification shall be meet with JAM101-94 and SAE JS526 b for automobile uses.
Dimension and specification
| O.D.(mm) | Thickness(mm) | Weight(g/m) | Assurance Pressure(kg/cm3) |
| 4.00 | 0.50 | 43.21 | 250 |
| 4.20 | 0.50/0.70 | 45.68/60.50 | 250 |
| 4.76 | 0.70 | 70.18 | 250 |
| 6.00 | 0.70 | 91.61 | 250 |
| 6.35 | 0.70 | 97.66 | 250 |
| 8.00 | 0.7/1.0 | 126.18/172.85 | 200 |
| 9.53 | 0.7/1.0 | 152.63/210.63 | 200 |
| 10.0 | 0.7/1.0 | 160.75/222.24 | 200 |
Chemical Composition
C ≤ 0.12%
Mn ≤ 0.50%
P≤ 0.04%
S≤ 0.045%
Mechanical properties
Tensile strength ≥30kgf/mm2
Yield point ≥18kgf/mm2
Elongation(50mm)≥25%
Hardness(HR30T)≤ 65
Tolerance of wall thickness
+/-0.08mm
