Carbon Molybdenum Alloy Steel Pipe Seamless For Boiler / Superheater

Price Negotiable

Price: negotiable

MOQ: 5Tons

Delivery Time: 30-45 work days

Brand: TORICH

Product Description

TORICH ASTM A209 Seamless Carbon-Molybdenum Alloy Steel Boiler and Superheater Tubes

Standard: ASTM A209 / A209M Seamless Carbon-Molybdenum Alloy-Steel Boiler and Super heater Tubes,Cold drawn and hot rolled seamless steel tubes for Boiler and Super heater
Applications: Boiler and Superheater Tubes
Size Range: OD:12.7-127mm WT:0.9-12.7mm
Steel Grade: T1, T1a, T1b
Manufacture: Killed steel material.
The tubes are made by seamless process either hot-finished or cold-finished
Seamless Carbon-Molybdenum Alloy-Steel Boiler and Super heater Tubes
Cold drawn and hot rolled seamless steel tubes for Boiler and Super heater.

STEEL GRADE AND CHEMICAL COMPOSITIONS
Seel Grade	C	Mn	P	S	Si	Mo
T1	0.10-0.20	0.30-0.80	≤0.025	≤0.025	0.10-0.50	0.44-0.65
T1a	0.15-0.25	0.30-0.80	≤0.025	≤0.025	0.10-0.50	0.44-0.65
T1b	≤0.14	0.30-0.80	≤0.025	≤0.025	0.10-0.50	0.44-0.65

Mechanical Properties
Seel Grade	Tensile strength(Mpa)	Yield Strength (Mpa)	δfixed (Pipe Segment S≥8mm vertical)	δfixed (S<8mm vertical)	δfixed (Round brilliant)
T1	≥380	≥205	≥30	See note	≥22
T1a	≥415	≥220	≥30	See note	≥22
T1b	≥365	≥195	≥30	See note	≥22
Note: S<8mm vertical Elongation is the basic value minus 1.5%,per wall thickness minus 0.8mm

HARDNESS
Seel Grade	HB S ≥5.1mm	HRB S≤ 5.1mm
T1	≤146	≤80
T1a	≤153	≤81
T1b	≤137	≤77

More products
Delivery condition and Heat treatment:
Cold Drawn Seamless and Hot Rolled Seamless need Heat treatment .minimum temperature is 650℃
If Delivery condition is annealing, isothermal annealing, normalizing+ tempering tempering minimum temperature is 650℃
Hot-finished tubes are heat treated at a temperature of 1200℉ (650℃) or higher.
Reference Documents:
ASTM A450/A450M Specification for General Requirements for Carbon, Ferritic Alloy, and Austenitic Ally Steel Tubes
ASTM A941 Terminology Relating to Steel, Stainless Steel, Related Alloys and Ferroalloys
