Alloy Steel Pipe Grades GCr15 JIS Standard JIS SUJ2 High Carbon Bearing Seamless Steel Pipe

SUJ2Chemical Composition:Gcr15 C Cr Si Mn P S Ni Cu MoWt% 0.95-1.051.40-1.650.15-0.350.25-0.45 ≤0.027 ≤0.02 <0.23 ≤0.25 ≤0.1GCr15 Sn As Ti Sb Pb 0 Al CaWt% <0.03 <0.04 <0.005 <0.002 <0.002 <0.001 <0.05 <0.01

Material S1541 GCr15 G4051 SUJ2 100Cr6(1.3505)

Size range: OD 4-114mm WT0.5-12mm

Characteristic

Bearing steel has high and uniform hardness and wear resistance as well as high elastic limit. Bearing steel is one of the most stringent steels in all steel production because of its strict requirements on the uniformity of chemical composition, the content and distribution of non-metallic inclusions, and the distribution of carbides. In 1976, ISO of the International Organization for Standardization (ISO) incorporated some general bearing steel numbers into the international standards, and divided the bearing steel into four categories: fully hardened bearing steel, surface hardened bearing steel, stainless bearing steel, high temperature bearing steel and a total of 17 steel grades.

Mill′s test certificate:EN 10204/3.1
