Seamless Honed Precision Steel Tube E355+C EN-10305 TORICH

Price Negotiable

Price: NEGOTIABLE

MOQ: 2 tons

Delivery Time: Within 30 days

Brand: TORICH

Product Description

Seamless Honed Precision Steel Tube E355+C EN-10305 TORICH

TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience.

Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless precision pipe, stainless steel seamless precision pipe.The material we usually use for producing Seamless Honed Precision Steel Tube is10#,20#,1010,1020,1026,ST37,ST44,E235,E215,E355

Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes
Applications: for Gas Cylinder Applications, Oil Cylinders/Telescopic Cylinders
Size Range: O.D.:6-380mm   W.T.:1-35mm   L:max12000mm
Steel Grade: E235, E355,E215 etc

Note: Special steel grade is also available, according to customer request.
aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm

Mechanical properties at room temperature
Steel Grade		Minimum values for the delivery condition
Steel Name	Steel Nubmer	(+Cc)		(+LCc)		(+SR)			(+Ad)		(+N) NBK
Steel Name	Steel Nubmer	Rm Mpa	A %	Rm Mpa	A %	Rm Mpa	ReH Mpa	A %	Rm Mpa	A %	Rm Mpa	ReH Mpa	A %
E215	1.0212	430	8	380	12	380	280	16	280	30	290-430	215	30
E235	1.0308	480	6	420	10	420	350	16	315	25	340-480	235	25
E355	1.0580	640	4	580	7	580	450	10	450	22	490-630	355	22
