Multi Pass Astm Fixed Tube Sheet Heat Exchanger
Product Overview:
Shell and tube heat exchangers consist of a cylindrical shell with a bundle of tubes inside it. They work by circulating a hot liquid inside the shell around the tubes, which contain a cooler liquid.
In a fixed tube sheet heat exchanger, the tubes are permanently positioned inside the shell and thus are not removable. In a multi-pass heat exchanger, the liquid passes through the tube bundle two or more times.
DAC Worldwide’s Multi-Pass Fixed Tube Sheet Heat Exchanger Training Model (286) is a highly-detailed scale model that teaches learners about the operation and maintenance of industrial multi-pass fixed tube sheet heat exchangers.
An accurate, to-scale replica of a typical industrial heat exchanger, the model features a clear acrylic shell and can be completely disassembled. It reflects design standards established by both the Tubular Exchanger Manufacturers Association (TEMA) and the American Society of Mechanical Engineers (ASME).
Features & Specifications
- Exact "to-scale" construction throughout (5" shell diameter).
- Clear acrylic shell, flanges, and nozzles.
- Contrasting opaque baffles and partitions.
- Detailed tube bundle.
- Representative, color-coded tubing for visibility and to show flow path.
- Opaque representative gaskets.
- Stainless steel hardware.
- Durable PVC baseplate with provision for tabletop mounting and mounting on related workstation and display rack products.
- Metal Trades Training Manual with a section on heat exchanger design, maintenance, and nomenclature (IPT).
- Packaging for shipment via motor freight.
