Stainless Steel 24v Brushless Motor for Floor Spring Door Operator 75W
Stainless Steel 24v Brushless Motor for Floor Spring Door Operator 75W
Applications:
Brushless motors are ideally suited for manufacturing applications because of their high power density, good speed-torque characteristics, high efficiency and wide speed ranges and low maintenance. The most common uses of brushless DC motors in industrial engineering are linear motors. servomotors, actuators for industrial robots, extruder drive motors and feed drives for CNC machine tools.
Description:
Brushless DC electric motor (BLDC motors, BL motors) also known as electronically commutated motors (ECMs, EC motors) are synchronous motors that are powered by a DC electric source via an integrated inverter/switching power supply, which produces an AC electric signal to drive the motor.
Specifications:
Motor data:
|
Type |
Brushless |
|
Voltage |
24VDC |
|
Power |
75W |
|
No-load speed |
9rpm |
|
On-Load speed |
7.5rpm |
|
Noise level |
≤40dB |
|
Gear Ratio |
1:248 |
|
Protection class |
IP55 |
|
Weight |
8.5kg |
|
Lifetime |
3million cycles,10years |
|
Application |
Automatic Floor Spring |
Floor Spring Door datas:
|
Max door weight |
250kg |
|
|
|
Max door width |
1400mm |
|
|
|
Max torque |
75Nm |
|
|
|
Install way |
Ground buried |
|
|
|
Electronic lock output |
DC 24V always open /always close contact |
|
|
|
Open and close time |
2-6 sec adjustable |
|
|
|
Close holding time |
0-30 sec adjustable |
|
|
|
Open range |
45° to 90°can be adjusted |
|
|
|
Power |
220V±10% 50-60HZ |
|
|
|
Rated current |
less than 1A |
|
|
|
Max power consumption |
35W |
|
|
|
Pending power consumption |
less than 2W |
|
|
|
Control device |
Specialized super heterodyne receivers, |
||
|
Work temperature |
(-40 to +80) |
|
|
|
Line index |
continuum running 3 million with no obstacles |
|
|
|
Protection grade |
IP55 |
|
|
|
Machine size |
L320mm*W185.6mm*H80mm |
|
|
|
Controller size |
L225mm*W195mm*70mm |
|
|
Competitive Advantage:
Brushless DC motor’s another advantage of a brushless motor is that it can operate at speeds above 10,000 rpm in both loaded and unloaded conditions. It is also capable of operating with less noise and electromagnetic interference than a brushed motor because its internal parts are completely enclosed.
