Mini Windshield Wiper Motor For Renault 45W , IP 44 wipers motor replacement
Mini Windshield Wiper Motor For Renault 45W , IP 44 wipers motor replacement
Description:
A windscreen wiper or windshield wiper is a device used to remove rain and debris from a windscreen or windshield. Almost all motor vehicles, including trains, watercraft and some aircraft, are equipped with such wipers, which are usually a legal requirement. A gear motor is driving device of the wiping system.
Suitable For Renault
VALEO Ref: 535 67 502
OEM No: 770106159/7701054828
Applications:
Automotive mini wiper motor widely used for all kinds of cars, trucks and buses
Specifications:
Wiper Motor Performance Data:
|
Type |
Brush |
|
Voltage |
12VDC |
|
Power |
30W |
|
No-load Speed |
40rpm |
|
No-load Current |
0.9A |
|
On-load Speed |
30rpm |
|
On-load Current |
1.9A |
|
Stall torque |
≥25Nm |
|
Gear material |
Nylon |
|
Protection class |
IP44 |
|
Rotate direction |
CW and CCW |
|
Weight |
1.5kg |
Wiper Motor Characteristic curves:
|
State |
Voltage |
Current |
Pin |
Torque |
Speed |
Pout |
Eff |
|
V |
A |
W |
N.m |
rpm |
W |
% |
|
|
Speed_max |
12.01 |
0.928 |
11.16 |
0.28 |
39.0 |
1.16 |
10.4 |
|
Eff_max |
12.00 |
4.945 |
59.36 |
7.07 |
29.5 |
21.84 |
36.8 |
|
Pout_max |
11.99 |
10.32 |
123.8 |
15.82 |
19.3 |
31.97 |
25.8 |
|
Torque_max |
11.97 |
19.15 |
229.3 |
26.18 |
0.0 |
0.00 |
0.0 |
|
End |
11.97 |
19.15 |
229.3 |
26.18 |
0.0 |
0.00 |
0.0 |
Competitive Advantage:
- Enhanced car styling
- Wipe angle correction - automatically delivers optimal wiping performance irrespective of windshield conditions (dry, damp, etc.)
- Electronic speed control - reduced noise at blade reversal points
- Obstacle detection - motor automatically compensates for windshield obstructions, such as snow block, and recalculates the appropriate wipe angle, limiting potential damage to the motor
