Temperature Humdity Control Walk-In Stability Test Chamber Programmable Modular Type
Easy Maintenance Programmable Modular Type Temperature Humdity Control Walk-In Chamber
Walk-In Type Temperature Test Chambers
Safety Protection:
Smoke detection
Gas detection
Flame detection
Visual alarm
Audible alarm
Extinction by gas
In case of a possible explosion of the tested element :
Inerting by nitrogen flush controlled by Spirale 3
O2 rate analyser
Explosive gas detector
Controlled relief valve or rupture disc
Air exhaust duct
Walk-In Chamber Types Knowledge:
| Model | Temperature Range | Humidity Range | Temperature Change rate | Recommended Test / Application |
| Panel Walk-in Chamber | -60°C to +85°C | 20% to 95%RH | 1 to 2°C/min | Temperature Cycling Temp / Humidity Cycling / Storage Testing |
| Solid Walk-In Chamber | -60°C to +150°C | 20% to 95%RH | 4 to 5°C/min, or faster | Temperature Cycling Temp / Humidity Cycling Extreme Temp / Humidity Testing Altitude Testing |
| Steady State Walk-In Chamber | -20°C to +50°C | 20% to 95%RH | N/A | Constant Temperature Constant Temp / Humidity Storage Testing |
Walk-In Chamber Main Technical Parameters
| Model | KMHW-17 | |||||||
| Volume(m³) | 35.2CBM | |||||||
| Interior Dimensions | W3900 x H2100 x D4300mm | |||||||
| Exterior Dimensions | W5050 x H2350 x D4500mm | |||||||
| Safety Devices(standard) | No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection | |||||||
| Standard accessories | Sight window*1, cable port ( portΦ50mm ) *1, chamber lamp*1, status indicator | |||||||
| Control System | Balanced Temperature & Humidity Control System | |||||||
| Refrigeration system | Water Cooled | |||||||
| Semi-hermetic compressor, single stage or cascade refrigeration system, | ||||||||
| CFC free refrigerant ( HFC-507 and HFC-23 ) | ||||||||
| Controller | Panel | 7-inch LCD Touch panel, Chinese or English display selectable | ||||||
| Operation model | Program or fix point running | |||||||
| Memory capacity | 120 programs,1200steps, all repeat 999 cycles,part repeat 99 cycles | |||||||
| Accuracy | Temp.:0.1% of F.S ± 1 digit Humidity:0.1% of F.S ± 1 digit | |||||||
| Input | Temp.: pt-100, Humidity: pt-100 or ～5V DCV | |||||||
| Comm.port | RS-232 or RS-485 ( Softawre is option) | |||||||
| Temp. range | Maximum: 80 ºC,120 ºC; Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC | |||||||
| Humidity Range | 10%, 20%, 30% ~ 95% | |||||||
| Temp. constancy | ±0.5 ºC | |||||||
| Humidity constancy | ±2.5%R.H | |||||||
| Temp. uniformity | ±2.0 ºC | |||||||
| Humidity uniformity | ±5.0%R.H | |||||||
| Ambient Temp. | +5 ºC～+35 ºC | |||||||
| Wiring method | AC 380 ± 10% 50Hz ,3 phase 4 wires + Ground Wires | |||||||
| Heat up time | +20 ºC～+80 ºC, Within 60 min | |||||||
| Pull down time | +20 ºC ~ -55 º, -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60 min | |||||||
| Interior material | Stainless Steel Plate(SUS 304) | |||||||
| Exterior material | Baked Painting Steel Or Stainless steel ( SUS304) | |||||||
| Insulation material | Rigid polyurethane foam | |||||||
| Door size (mm) | Single wing: W800 x H1800; Double wing: W1600 x H1800; | |||||||
| Note:1. We reserve the right to change specifications without prior notice 2.Customized sizes and configurations available | ||||||||
KOMEG Temperature Humidity Test Chamber Features:
The refrigerating system is the core/heart part of the test chamber.
For enhance the whole refrigerating system performance, we use professional and advanced copper tube bending machine, this can decrease the welding points over 50%, and decrease right-angles of the tube, Also less welding points can reduce the resistance when the liquid flowing inside, to keep compressor working in higher efficiency, and better energy-saving.
And for welding the copper tube, we use Liquid Nitrogen protection welding technology, this can better protect the tube and keep the cooling system clean.
All this will do good to the compressor.
We use GEA Bock semi-hermetic compressor. According to our over 20 years experiences in this climatic test chambers field, GEA Bock Compressor has excellent performance in refrigerating effect and running stability; has good noise control, also energy-saving.
most customizable, with Germany GEA Bock Compressor.
The description is sourced from climatictestchambers.com, for more detailes please refer to our website.
