Car / truck / bus H.264 3G live video 4CH SD Card Mobile Vehicle DVR with GPS WIFI
H.264 3g live video 4ch SD Card Mobile DVR with GPS WIFI for car / truck / bus
Features:
- Mini 3G Mobile DVR, 4 channel, GPS, 3G,WIFI . which wifi also support 5ghz and2.4 ghz.
- H.264 ,VOICE Talking
- Sending alarm sms to Mobile phone
- 36 types smart alarm
Specifications:
- H.264 main profile Video compression format, Support 1 to 4 channels video input.
- Industrial grade design, adopt most industrial materials including the industrial connectors special for mobile dvr.
- Built-in GPS, WIFI, G sensor, Gyro sensor optional. which wifi support 5 ghz and 2.4 ghz.
- 2 SD Card slots optional,VOIP
- Built-in wireless module like 3G (EVDO, WCDMA,HSPA, HSDPA, TD-SCDMA…), GPRS…optional.
- Real time recording, 100f/s (PAL), 120f/s (NTSC). maximum support 2CH of D1 & 2CH of CIF .
- 8-36V wide voltage supply design, Very good anti-vibration
- Upload the alarm video automaticlly to CMS
- Remote voice communication to driver, Remote messages,Over speed alarm
- All materials up to RoHs standard .
- Elegant and industrial design, Mini size, for easy installation, more concealling.
- Dimensions, 112(W) x36(H) x138(D) mm, Weight, 0.45KG,
- Smart alarm up to 36 types ,such as over speed driving remind,pre-alarm and alarmemergency alarm
- detect the abnormal operation of the door
- prevent robbery alarm
- corss boarder alarm
- hard brake/acceleration/turns alarm etc
Product Parameters:
|
Operating System |
Linux (2.6) |
|
|
Video Compression |
H.264 main profile. ARM9, 10bit chipset processor. |
|
|
GUI |
Graphical User Interface |
Setup system parameters through the remote control. |
|
Video and Recording System |
Video input |
1-4 channels input, 4 CVBS, 1.0Vp-p, 75Ω |
|
Video output |
1CH output, CVBS, 1.0Vp-p, 75Ω, |
|
|
Preview |
Support 1 channel or synchronous 4 channels preview. |
|
|
Recording Resolution |
Support CIF,HD1,D1 resolution optional, maximum 2CH of D1 ,2CH of CIF |
|
|
Video Quality |
1-4 levels, 1 is the highest level , 4 is the lowest level. |
|
|
Recording Mode |
support timed recording, alarm recording, manual recording. |
|
|
Audio |
Audio Input |
Mic or line in, up to 2 channels |
|
Audio Output |
1 channel output, output voltage, 1V ~2V |
|
|
Compression |
G.726, 5KB/s |
|
|
Alarm |
Input |
Support up to 4 channels alarm input. |
|
Alarm recording, |
include the recording within 15 seconds ahead of the alarm starting |
|
|
Output |
2Ch alarm output, level signal. |
|
|
Communication Port |
RS232 for remote control, RJ45 10M/100M Ethernet port. |
|
|
GPS and G-Sensor, Gyro-sensor |
built-in GPS module optional. With G-Sensor to induce the vehicle X, Y, Z axis |
|
|
3G,WIFI Wireless transmission |
Built-in wireless module optional. Such as 3G EVDO, HSPA, HSDPA, WCDMA…GPRS, EDGE |
|
|
Playback System |
Video Search |
Search video via time, type(normal or alarm), |
|
Playback |
Support 1 or synchronous 4 channels playback. |
|
|
Support forward at the speed of, x 2,x4,x8,x16. |
||
|
Storage |
SD Card |
Support 2 SD Cards, 128GB for each at max(default 1 card supported). |
|
Power |
Power Management |
1,Vehicle acc on/off 2.Preset time |
|
Power Supply |
DC,+8V ~ +36V |
|
|
Power Output |
+12V 1.5A,+5V 1.5A |
|
|
Power consum |
Normal working state <5W, Idle state<0.5W |
|
|
Power-off data protection |
Special UPS technique that the machine can still record video for 10 to 15 seconds after the outside power off |
|
|
Security |
Password |
User and Admin, 2 levels password management |
|
Working Environment |
Temperature |
-20 to +70 |
|
Humidity |
20% to 80% |
|
|
Others |
Dimensions |
112(W) x36(H) x138(D) mm |
|
Net Weight |
450g |
|
H.264 3g live video 4ch SD Card Mobile DVR with GPS WIFI for car / truck / bus
