Rugged 3G Car DVR GPS WIFI 128GB High Security Safety For School Bus / Taxi / Truck
HD SD Card 4ch rugged 1080P Car dvr with 3g gps wifi support 128GB sd card (M605HD)
Main Features:
1. H.264 Compressiona format
2. Support 3G GPS wifi
3. Compact size, much easier for installation.
4. Can use ignition to control the power.
5. Support 3 sensors, record brake, return, right turn, left turn light status into the record file.
Product's Pictures:
Specifications:
| Item | Description | Parameter |
| System | Language | English |
| Interface | IE Interface | |
| Security | Administrator and user password protected | |
| Video | Video Sensor | 1920×1080, 1/2.7" Progressive Scan CMOS |
| Video Standard | 1920×1080, 30fps | |
| Audio | Audio Input | 1/2/4 channel audio input |
| Recording mode | Audio and video synchronize | |
| Compression | AAC | |
| Storage |
Video Compression | H.264 High Profile |
| Resolution | 1080P at 120fps | |
| Video bitrate | 720p: 200Kbps ~ 8Mbps | |
| Audio bitrate | 8KB/s | |
| Storage | SD card,USB2.0 port(For flash disk or hard drive) | |
| Format | AVI | |
| Sensor | Sensors | 1 speed sensor, 1 ignition sensor, 3 common use sensors |
| Communication | WiFi | 802.11b/g/n, max 300M |
| Network | RJ45,10M/100M Lan port | |
| COM | Two RS232 connector and one RS485 connector | |
| GPS | supported | |
| Software | Player | |
| 3rd party player | VLC media player,Storm player,WINAMP | |
| Firmware update | Via SD card or USB disk | |
| Power | Power input | DC:+8V ~ +32V |
| Power output | +12V at 1.5A,+5V at 1A | |
| Power consumption | Less than 5W,less than 0.1W in standby mode | |
| Working temperature | -10 ~ +60 | |
| Size | 9.2CM(Width)×2.0CM(Height)×11.7CM(Length) | |
Advantages:
Low bitrate for longer time recording with smart technology
The High Definition 1080P MDVR uses intelligent bitrate control to save media space when doing H.264 image compression. If no obvious moving in scope, the bitrate will be reduced to 50% of the set value automatically.
Video live view or download through WiFi (built-in)
Administrative personnel can use a laptop/smart phone/iPad to connect to the DVR to view and/or download videos. Allow three authorization levels for security access.
Highlighted features with 3G/4G network
l Remotely Live view & GPS tracking on Google Map;
l GPS track playback;
l Geo-fencing with optional GPS receiver;
l One picture will be sent to server as well as email alert when an alarm is triggered;
l Reports for Speed, Alarm, Stop, Geo-fencing, Fuel, etc.
