4 Channel Full HD 256GB SD Card AHD Mobile DVR Built In GPS 3G 4G WIFI
4 Channel Full HD 256GB SD Card AHD Mobile DVR Built In GPS 3G 4G WIFI
Main Features:
1. H.264 Video Compression,Support 4CH 720P AHD Camera input;
2. Exclusive pre-allocated file system, solve the file fragmentation / SD lost / file garbled etc issue,protect data file;
3. 10-36V Wide Voltage, Lower power consumption;
4. SD Card Storage ( Dual SD Card, each max 128GB ),
5. Support 3G/4G GPS WIFI, GPS/BD/G-sensor module;
6. High vibration Aviation plug.
Specifications:
|
Item |
Parameter |
|
|
OS |
Linux |
|
|
Language |
Chinese/English/Customized |
|
|
Video Compression |
H.264 |
|
|
Video Record System |
Video Input |
4CH 720P AHD input,aviation connector, 1.0Vp-p, 75Ω |
|
Video Output |
1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen |
|
|
Preview |
Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview |
|
|
Resolution |
720P/D1/HD1/CIF, MAX:4 channels of 720P and 4 channels of D1 |
|
|
Video Quality |
1-4 levels, 1 is the highest level. |
|
|
Record Mode |
The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported. |
|
|
Audio |
Audio Input/Output |
4CH ,Aviation Plug, 1CH,Aviation Plug |
|
Compression |
G.726 compression, 8KB/s speed |
|
|
Alarm Input/Output |
3Ch Alarm Input, kinds of alarm linkage support, 1CH Alarm Output |
|
|
Position |
Support Built GPS/BD Module |
|
|
G-Sensor |
Support G-sensor |
|
|
Storage |
SD |
Dual SD Card,each max 128GB SD Card loop recording |
|
Upgrade |
Support SD Card updating |
|
|
File Format |
H.264 |
|
|
File System |
Special FAT32 File System |
|
|
Video Playback |
Video Search |
Search By Record Time/Record Type etc |
|
Playback |
Max support 4CH Replay /Stop/Fast/Slow at same time |
|
|
Support forward and backward play at the speed of: x 2,x4,x8,x16. |
||
|
Voltage & Power |
Power Management |
Wide Voltage.Support Timed/Delay off |
|
Voltage Input |
DC:+10V ~ +36V |
|
|
Voltage Output |
+12V@2.5A,+5V@2.5A |
|
|
Power Consumption |
Normal Working ＜5W |
|
|
others |
Size |
112(W) x36(H) x138(D) mm |
|
Net Weight |
360g |
|
