H.264 Dual SD Cards 3G WIFI Car 4 channel Mobile DVR With GPS Tracking

Price Negotiable

Price: negotiation

MOQ: 1 Unit

Delivery Time: 4ch SD Cards Mobile DVR SAMPLE Available within 3 weekdays

Brand: RECODA

Product Description

H.264 Dual SD Cards 3G WIFI Car 4 channel Mobile DVR With GPS Tracking

Specifications:

4CH full D1 high resolution recording.
3G/4G LTE, GPS and WIFI functions optional.
Capable of remote PTZ and two-way talk.
Other functions incl. "geo fence, batch configuration, 3G-WIFI auto switch etc."
Rich external devices to link such as "LED panel, Advertising screen, RFID, oil sensor"
Support CAN, OBD etc.
Flexiable upgrade, locally or remotely with dual-flash strategy, no data loss.
Up to 128GB SD storage, MINI size and shockproof.
CE, FCC certified.
SDK available for future development.
Factory 12 months warranty, OEM and LOGO accepted.

Parameters:

OS		Linux
Language		Chinese/English/Customized
Video Compression		H.264
OSD		Overlays information such as date time and vehicle ID
GUI	Graphical User Interface	Setup system parameters with the remote control.
Video Record System	Video Input	4CH CVBS video input,aviation connector, 1.0Vp-p, 75Ω
	Video Output	1CH CVBS output, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen
	Preview	Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview
	Resolution	720P/D1/HD1/CIF, MAX:4 channels 720P
	Video Quality	0-7 levels, 0 is the highest level.
	Video Standard	PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional;
	Record Mode	The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.
Audio	Audio Input	4CH ,Aviation Plug
	Audio Output	1CH,Aviation Plug
	Compression	G.726 compression, 8KB/s speed
Alarm Input		4Ch Alarm Input, kinds of alarm linkage support
Alarm Output		1CH Alarm Output
Communication interface		2CH RS232 or 1CH RS485 for optional
Position		Support Built GPS/BD Module, built in G-sensor, can repaly and analyse vehicle driven route.
wireless transmission		Suppport Built-in 3G/4G wireless transmission function, WCDMA, CDMA2000, TDD-LTE, FDD-LTE....
Motion Detection		Support motion detection alarm. (Can set the video recording duration time after alarm on platform.)
G-Sensor		Support G-sensor
Storage	SD	Dual SD Card,each max 128GB SD Card loop recording
	Upgrade	Support SD Card remote updating
	File Format	H.264
	File System	Special FAT32 File System
Video Playback	Video Search	Search By Record Time/Record Type etc
	Playback	Max support 4CH Replay /Stop/Fast/Slow at same time
	Playback	Support forward and backward play at the speed of: x 2,x4,x8,x16.
Voltage & Power	Power Management	Wide Voltage.Support Timed/Delay off
	Voltage Input	DC:+8V ~ +36V
	Voltage Output	+12V 2.5A,+5V 2.5A
	Power Consumption	Normal Working <14W , Stand-by status < 0.5W
Security	Password	User/Admin 2 Level Different Password
