4G GPS WIFI AHD Hybrid HDD Mobile DVR 8CH 1080P 720P For Truck School Bus Lorry Taxi
4G GPS WIFI AHD Hybrid HDD Mobile DVR 8CH 1080P 720P For truck school bus lorry taxi
Mobile DVR Advantages:
Power source for up to 4 cameras.
Record quality footage for review, donload, and inspection.
Transimits SOS alarm via CMS software to the control center to react quickly.
Mobile DVR Applications:
Buses, Coach, Logistic Trucks, Tractors, Police Cars, Taxi
Armored cars, Public security and law enforcement vehicles
Ambulances, Traffic duty vehicles and other fields.
Mobile DVR Specification:
| Item | Parameter | |
| OS | Linux | |
| Language | English/Chinese/Customized | |
| Video Compression | H.264 Compression | |
| OSD | Overlays information such as date time and vehicle ID | |
| GUI | Graphical User Interface | Setup system parameters with the remote control. |
|
Video Record System |
Video Input | 8CH 1080P AHD input,aviation connector, 1.0Vp-p, 75Ω |
| Video Onput | 1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen view | |
| Preview |
Support 1 channel and 4 channels preview., Support Manual/Alarm Trigger full screen preview |
|
| Resolution | 720P/D1/HD1/CIF, MAX:4 channels of 720P | |
| Image Quality | 1-4 levels, 1 is the highest level. | |
| Video Standard |
PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional; 720P: 4Mbps-6Mbps, multi level video quality optional |
|
| Voltage & Power | Power Management | Wide Voltage.Support Timed/Delay off |
| Input Voltage | DC:+10V - +36V | |
| Output Voltage | +12V~1.5A,+5V~1.5A | |
| Power | Working <5W | |
| Working Environment | Temperature | -20℃ - +70℃ |
| Humidity | 20% - 80% | |
| Ohters |
Size
|
218 (D)* 161(W)* 65(H) mm |
| Weight | 2.2 Kg |
