Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Price:
45770-50128
MOQ:
1
Delivery Time:
one month
Brand:
GPRO
Product Description
Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
| Technical specification | |
| Genset Model | GP688CCS |
| Prime Power | 500KW/625KVA |
| Standby Power | 550KW/688KVA |
| Phase Number | 3 |
| Power Factor | 0.8 |
| Rated Voltage | 230/400V |
| Frequency | 50 HZ |
| Rated Current | 902A |
| Genset Structure | SILENT |
| Dimension | 5000×1800×2450mm |
| Net Weight | 5500KG |
| Noise level | 83dB at 7 meters |
| Fuel Tank Capacity | 800L |
| Engine Model | KTAA19-G6A |
| Engine Features | 6-cylinder,4 stroke,water cooled ,Turbo |
| Bore * Stroke | 159mm × 159mm |
| Displacement | 18.9L |
| MAX Power(kw) | 575KW/1500 |
| Fuel Consumption L/H | 129.5L/H |
| Compression Ratio | 13:01 |
| Governor type | ELECTIC |
| Alternator Model | STAMFORD /HCI544FS |
| Excitation Mode | brushless self-excited |
| Insulation Class | H |
| Protection Class | IP23 |
| Construction Type | SAE Disc-coupling |
| Controler panel | |
| Smartgen 6120 | intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator |
