SG Type Electric Mini Chain Hoist With Capacity 500kg , Lifting Speed 8m/Min
Price:
Negotiable
MOQ:
50pcs
Delivery Time:
30 days
Brand:
SEAGULL
Product Description
SG Type Electric mini Chain hoist capacity 500kg,lifting speed 8 m/min color optional
Product Description
-
With suspension hook. push, geared or electric trolley.
-
Standard lift height 3 m, control cable 3m
-
Operating voltage 220-460V, 50/60Hz, 1-3 phase
-
Low voltage control 24V is standard.
-
High efficient energy-saving motor, asbestos free brake system.
![]()
Technical Parameters
| SG ELECTRIC HOIST | |||||||||
| Work class | M3 | M4 | M5 | M6 | M7 | ||||
| 150 | 180 | 240 | 300 | 360 |
Lifting speed |
Lifting height |
Power km |
Weight |
|
| %ED | 25% | 30% | 40% | 50% | 60% | ||||
| Model | Capacity | ||||||||
| SGXXX/1N | 500 | 400 | 320 | 250 | 200 | 8 | 3 | 0.8 | 25 |
| SGXXX/1NF | 500 | 400 | 320 | 250 | 200 | 8/2 | 3 | 0.8/0.2 | 25 |
| SGXXX/1S | 320 | 250 | 200 | 160 | 125 | 12.5 | 3 | 0.8 | 25 |
| SGXXX/1SF | 320 | 250 | 200 | 160 | 125 | 12.5/3 | 3 | 0.8/0.2 | 25 |
| SGXXX/1H | 200 | 160 | 125 | 100 | 80 | 20 | 3 | 0.8 | 25 |
| SGXXX/1HF | 200 | 160 | 125 | 100 | 80 | 20/5 | 3 | 0.8/0.2 | 25 |
| SGXXX/2N | 1000 | 800 | 630 | 500 | 400 | 4 | 3 | 0.8 | 27 |
| SGXXX/2NF | 1000 | 800 | 630 | 500 | 400 | 4/1 | 3 | 0.8/0.2 | 27 |
| SGXXX/2S | 630 | 500 | 400 | 320 | 250 | 6.3 | 3 | 0.8 | 27 |
| SGXXX/2SF | 630 | 500 | 400 | 320 | 250 | 6.3/1.5 | 3 | 0.8/0.2 | 27 |
| SGXXX/2H | 400 | 320 | 250 | 200 | 160 | 10 | 3 | 0.8 | 27 |
| SGXXX/2HF | 400 | 320 | 250 | 200 | 160 | 10/2.5 | 3 | 0.8/0.2 | 27 |
Certification
![]()
ISO9001:2008 TUV CE ECM CE
more information pleasedownload the PDF:
