Deep Cycle Solar Lead Acid Battery 4ah 12v Rechargeable Batteries For UPS
Deep Cycle Solar Lead Acid Battery 4ah 12v Rechargeable Batteries For UPS
Description:
| Place of Origin: |
Guangdong, China (Mainland)
|
Brand Name: | Champion | Model Number: |
6FM4
|
| Usage: |
UPS,deep cycle
|
Voltage: |
12v
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
90*70*101mm
|
Weight: |
1.45kg
|
| Nominal Capacity: |
4ah
|
Terminal Type: |
F1 or F2
|
Warranty: |
12 Months
|
| Total Height: |
106mm
|
Battery Type: |
AGM Battery
|
Color: |
Black, green or other for option
|
| OEM: |
Available
|
Logo printing: |
Free
|
Container Material: |
Strong ABS
|
Applications:
Specifications:
| Product Name |
12v 5ah battery |
||
|
Capacity (25°C) |
20HR(10.5V) |
4Ah |
|
|
10HR(10.5V) |
3.7Ah |
||
|
1HR(9.60V) |
2.25Ah |
||
|
Dimension |
Length |
90±1mm (3.54inch) |
|
|
Width |
70±1mm (2.76inch) |
||
|
Height |
101±1mm (3.98inch) |
||
|
Total Height |
107±1mm (4.21inch) |
||
|
Approx. Weight |
1.45kg |
||
|
Terminal type |
F1/F2 |
||
|
Internal resistance (Fully charged, 25°C) |
Approx. 26mΩ |
||
|
Capacity affected by temperature (20HR) |
40°C |
102% |
|
|
25°C |
100% |
||
|
0°C |
85% |
||
|
-15°C |
65% |
||
|
Self-discharge (25°C) |
3 month |
Remaining Capacity: 91% |
|
|
6 month |
Remaining Capacity: 82% |
||
|
12 month |
Remaining Capacity: 65% |
||
|
Nominal operating temperature |
25°C±3°C(77°F±5°F) |
||
|
Operating temperature range |
Discharge |
-15°C~50°C(5°F~122°F) |
|
|
Charge |
-10°C~50°C(14°F~122°F) |
||
|
Storage |
-20°C~50°C(-4°F~122°F) |
||
|
Float charging voltage(25°C) |
13.60 to 13.80V Temperature compensation: -18mV/°C |
||
|
Cyclic charging voltage(25°C) |
14.50 to 14.90V Temperature compensation: -30mV/°C |
||
|
Maximum charging current |
1.5A |
||
|
Terminal material |
Copper |
||
|
Maximum discharge current |
75A(5 sec.) |
||
|
Designed floating life(20°C) |
3~5 years |
||
Competitive Advantage:
- Sealed and maintenance free, safety, no leakage
- ABS containers and covers optional
- With safety valve
- High quality and reliability
- Exceptional deep discharge recovery
- Flexible design for multiple installation
- Wide operating temp. range
- High capability, high energy density
- Long service life
-
Excellent safety, discharging, shock-proof and impact proof performance
- Good resistance to overdischarge, overcharge and high current
- Made by shenzhen battery factory
During the expected float service life of CHAMPION batteries, there is no need to check the specific gravity of the electrolyte, or add water. In fact, there is no provision for these maintenance functions.
