6 Voltage 225 AH Gel Lead Acid Battery M8 Terminal For Off Grid
6 Voltage 225 AH Gel Lead Acid Battery M8 Terminal For Off Grid
Description:
Champion 6V 225AH Deep cycle gel battery is very suitable for off grid power system, wide used in Africa solar projects,and be accepted with high praise for many years,due to Champion's good reputation of battery manufacturing for past 16 years,and with only 0.1% failure rate, 10 times less than average from China's competitors.
products data :
| 3FM36G | 6 | 36 | 162 | 88 | 164 | 170 | F2 | 5 | 5.5 |
| 3FM42G | 6 | 42 | 6.1 | ||||||
| 3FM100G | 6 | 100 | 194 | 170 | 205 | 210 | M8 | 4 | 15.5 |
| 3FM150G | 6 | 150 | 260 | 180 | 245 | 250 | M8 | 5 | 23 |
| 3FM180G | 6 | 180 | 307 | 169 | 220 | 225 | M8 | 5 | 27 |
| 3FM200G | 6 | 200 | M8 | 29 | |||||
| 3FM200G | 6 | 200 | 321 | 176 | 226 | 229 | M8 | 4 | 29.5 |
| 3FM225G | 6 | 225 | 321 | 176 | 226 | 229 | M6 | 5 | 31 |
| 3FM300G | 6 | 300 | 295 | 178 | 345 | 348 | M8 | 5 | 47 |
Applications:
1) Golf Cars, Wheelchairs& Electric Power Vehicles
2) Power Tools, Lawn Mowers & Vacuum Cleaners
3) Electric Toys & Recreation Equipments
4) Solar & Wind Power Generation Systems
5) Lighting Equipments
Specifications:
| Place of Origin: |
Guangdong, China (Mainland)
|
Brand Name: |
Champion
|
Model Number: |
3FM225G
|
| Type: |
Deep cycle GEL Battery
|
Nominal Voltage: |
6V
|
Size: |
321*176*226 mm
|
| Nominal Capacity: |
225AH
|
name: |
Battery 6v225ah for golf cart,Deep cycle battery for motive power
|
certifate: |
CE
|
| sample: |
available
|
service: |
OEM
|
container: |
ABS
|
| printing color: |
white
|
warranty time: |
2 years
|
usge: |
Golf cart /golf trolley or motive power
|
| Capacity 77°F(25°C) | 20 hours rate(10.4A 5.4V) | 233Ah | ||||
| 10 hours rate(20A 5.4V) | 225Ah | |||||
| 5 hours rate(35A 5.25V) | 200Ah | |||||
| 1 hour rate(130A 4.8V) | 155Ah | |||||
| Internal Resistance | Full charged battery 77°F(25°C):4mΩ | |||||
| Capacity affected by Temperature (10 hour rate) | 104°F(40°C) | 102% | ||||
| 77°F(25°C) | 100% | |||||
| 32°F(10°C) | 85% | |||||
| 5°F(-15°C) | 65% | |||||
| Self-Discharge 68°F(20°C) | Capacity after 3 month storage | 90% | ||||
| Capacity after 6 month storage | 80% | |||||
| Capacity after 12 month storage | 60% | |||||
| Max discharge current77°F(25°C):1000A(5S) | ||||||
| Charge (Constant Voltage) | Float:6.8 to 6.9V/77°F/(25°C) | |||||
| Cycle:7.25 to 7.45V/77°F/(25°C) | ||||||
| Max Current:50A | ||||||
Competitive Advantage:
- Excellent safety performance.
- Good discharging performance.
- Good impact-proof performance.
- Good resistance to over discharge.
- Good resistance to overcharge.
- Good resistance to high current.
