Light Weight 12v40ah UPS Lead Acid Battery High Discharge Rate
Light Weight 12v40ah UPS Lead Acid Battery High Discharge Rate
Description:
Solar Gel batteries are an intricate component for off-grid electrical systems such as solar, wind, and mini hydroelectric systems.
All these systems produce DC electrical which must be stored so that it may be used at a later time. In order to do this at the present time we use deep cycle batteries.
Deep cycle batteries are used because they have the ability to be recycled many times. This means that they can go from being charged to being discharged to 50% numerous times without damaging the batteries unlike that of other batteries such as cranking batteries which are used to start vehicles.
The innovative Gel Technology does not only combines the advantages of lower internal resistance of deep cycle battery , but also do have much better thermal stability and longer cyclic life .
Applications:
Cycle Use
Portable VTR/TV, tape recorders, radio, etc.
Power tools, lawn mowers, vacuum cleaners
Cameras and photographic equipment
Portable personal computers, word processors, portable terminals, etc.
Portable measuring equipment
Portable telephone sets
Various power toys and hobby equipment
Lighting equipment
Standby Use
Communications and electric equipment
Emergency lighting equipment
Fire alarm and security systems
Various telemeter equipment
Office computers, microcomputers, and other office automation equipment
Robots, control equipment, and other factory automation equipment
UPS power supply
Emergency power supply in power generation plants and substations
Deep cycle Use
Solar Cell Power Generation
Street Lighting
Water pumping system
Portable power supply
Small town power system
Specifications:
|
Model |
Voltage |
Capacity |
Dimension(mm) |
Terminal |
Weight |
|||
|
(V) |
(Ah) |
L |
W |
H |
TH |
Type |
(Kg±3%) |
|
|
6FM33 |
12 |
33 |
195 |
130 |
155 |
166 |
F14 |
10 |
|
6FM40 |
12 |
40 |
197 |
165 |
170 |
170 |
F14 |
12.5 |
Quick Details
| Place of Origin: |
Guangdong, China (Mainland)
|
Brand Name: |
Champion
|
Model Number: |
12V 40Ah
|
| Usage: |
Solar systems
|
Voltage: |
12v
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
197*165*170 mm
|
Weight: |
12.5 Kg±0.15Kg
|
| Nominal Capacity: |
40Ah
|
Company established year: |
2000
|
Certificate: |
ISO,CE,UL,ROHS
|
| Cycle use: |
14.6-15.0V
|
Standby use: |
13.5-13.8V
|
Designed life: |
12 years
|
Competitive Advantage:
- Low self discharge characteristic.
- Good tolerance to higher temperature applications.
- ABS containers and covers(UL94HB, UL94V-0) optional.
- Extra durability and deep cycle ability for heavy demand applications.
- Higher safety & reliable construction.
- Safety valve installation for explosion proof.
- Ideal for cyclic uses
