Solar power use 12v lead acid battery 50ah gel or agm type deep cycle battery
solar power use 12v lead acid battery 50ah gel or agm type deep cycle battery
Description:
12V 50AH gel lead acid battery,agm vrla battery Specification
| Nominal Valtage | 12V |
| Nominal Capability | 50Ah@10 hour rate F.V.(1.8v/cell) |
| Approx. Weight | 15Kg |
| Terminals | B2 (Fitting M8 bolt & nut) I2 is optional |
| Internal Resistance | ≤7.5m Ω(Fully Charged) |
| Max. Discharge Current | 500A (5 sec) |
| Max. Charge Current | 12.5A |
| Operating Temperature Range |
Charge: -10°c~40 °c (-14°F~104 °F) |
| Self Discharge | About 3% of capacity declined per month at (25 °c ) |
| Place of Origin: |
Guangdong, China (Mainland)
|
Brand Name: | CHAMPION | Model Number: |
12V50AH
|
| Usage: |
UPS
|
Voltage: |
12v
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
229*138*210
|
Weight: |
15KG
|
| Nominal Capacity: |
50AH
|
Low self discharge:: |
no charge six months storage at room temperature
|
Safety: |
There are no internal relief valve isolation sparks explosion
|
| Long life:: |
3-5 years normal use
|
Vrla Agm battery lead:: |
99.994% purity lead
|
Color:: |
Grey or Black
|
| Container Material:: |
ABS
|
Certification:: |
UL,CE,ISO9001,ISO14001
|
Delivery time :: |
25days
|
Applications:
UPS, Broadband, Electric powered vehicles, Electric powered toys, Vacuum cleaners, Medical Equipments, Goof cars and buggies, Wheel chairs, PVs, solar systems, control systems, power systems, wind energy systems, telecommunication /communication systems & etc.
Specifications:
| Noninal Voltage | 12V | |
| Capacity(10HR,25℃) | 50AH | |
| Designed Life | 10 Years | |
| Dimension | Length | 228mm |
| Width | 138mm | |
| Height | 210mm | |
| Total Height | 224mm | |
| Reference Weight | 15kg | |
Charateristics
|
Capacity 25℃ (77℉) To 1.70V/Cell |
||
| 10 hr rate(5.5A) | 50Ah | |
| 5 hr rate(8.8A) | 39Ah | |
| 1 hr rate(33A) | 28Ah | |
| Inner Resistance(fully charged 25℃) | 6.5mΩ | |
| Self-discharge (at 25℃.) : | 3% of the capacity per month | |
| Discharge Temperature | -20~60℃ | |
| Charge Temperature | -10~60℃ | |
| Storage Temperature | -20~60℃ | |
| Cyclic charging voltage (at 25℃) | 14.4~14.9V | |
| initinal current (at 25℃) | 20A | |
| Temperature Compensation | -30mV/℃ | |
| Float Use (at 25℃) | 13.6-13.8V | |
| Temperature Compensation (at 25℃) | -20mV/℃ | |
Competitive Advantage:
• Living Up to Prevailing Standards
• Good deep discharge cycle capability
• Excellent Recovery from Deep Discharge
• Longer Service Life
• High Reliability and Quality
