12 Volt Vrla AGM Lead Acid Battery 9ah Deep Cycle UPS Battery Replacement Long Life Type

Price Negotiable

Price: negotiation

MOQ: 500

Delivery Time: 25 days

Brand: Champion

Product Description

12v AGM vrla Lead Acid Battery 9ah deep cycle long life type for UPS and security

Description:

Quick Details

Place of Origin:	Guangdong, China (Mainland)	Brand Name:	CHAMPION	Model Number:	6FM9
Usage:	UPS, backup power supply	Voltage:	12v	Sealed Type:	Sealed
Maintenance Type:	Free	Size:	1516594mm	Weight:	2.4kg
Nominal Capacity:	9AH	Warranty:	13 Months	Color:	Black, green or other for option
OEM:	Available	Container Material:	ABS	Certificates:	CE/ROHS

Applications:

1) Communication Systems: Switch, Microwave Stations, Mobile Base Stations, Data Centers, Radio and Broadcasting Stations.
2) EPS & UPS Systems
3) Solar & Wind Power Generation Systems
4) Signal System & Emergency Lighting Systems
5) Motivity Field: Robots, Electric Toys, Electric Tools & Portable Vacuum Cleaners

Specification:

Product Name		12v 9ah battery
Capacity (25°C)	20HR(10.5V)	9Ah
	10HR(10.5V)	8.4Ah
	1HR(9.60V)	5.8Ah
Dimension	Length	151±1.5mm (5.94inch)
	Width	65±1mm (2.56inch)
	Height	94±1mm (3.70inch)
	Total Height	100±1mm (3.94inch)
Approx. Weight		2.4kg
Terminal type		F1/F2
Internal resistance (Fully charged, 25°C)		Approx. 19mΩ
Capacity affected by temperature (20HR)	40°C	102%
	25°C	100%
	0°C	85%
	-15°C	65%
Self-discharge (25°C)	3 month	Remaining Capacity: 91%
	6 month	Remaining Capacity: 82%
	12 month	Remaining Capacity: 65%
Nominal operating temperature		25°C±3°C(77°F±5°F)
Operating temperature range	Discharge	-15°C~50°C(5°F~122°F)
	Charge	-10°C~50°C(14°F~122°F)
	Storage	-20°C~50°C(-4°F~122°F)
Float charging voltage(25°C)		13.60 to 13.80V Temperature compensation: -18mV/°C
Cyclic charging voltage(25°C)		14.50 to 14.90V Temperature compensation: -30mV/°C
Maximum charging current		2.7A
Terminal material		Copper
Maximum discharge current		135A(5 sec.)
Designed floating life(20°C)		3~5 years

Model	Voltage	Capacity	Dimension(mm)				Terminal	Terminal	Weight
Model	(V)	(Ah)	L	W	H	TH	Type	Position	(Kg±5%)
6FM0.8	12	0.8	96	25	62	62	AMP		0.34
6FM1.2	12	1.2	97	43	52	58	F1	2	0.55
6FM2	12	2.0	178	35	61	67	F1	6	0.80
6FM2.2	12	2.2	178	35	61	67	F1	6	0.83
6FM2.3	12	2.3	178	35	61	67	F1	6	0.90
6FM2E	12	2.0	70	48	98	104	F1	6	0.75
6FM2.3E	12	2.3							0.80
6FM2.6	12	2.6							0.85
6FM2.5	12	2.5	104	48	70	70	+F2-F1	2	0.90
6FM2.8B	12	2.8	104	48	70	70	+F2-F1	2	0.98
6FM2.8	12	2.8	67	67	97	103	F1	6	1.00
6FM2.8A	12	2.8	132	33	98	104	F1	6	1.00
6FM2.9	12	2.9	79	56	99	105	F1	3	1.05
6FM3.2	12	3.2	134	67	61	67	F1	2	1.25
6FM4	12	4.0	90	70	101	107	F1/F2	6	1.36
6FM3.6	12	3.6							1.25
6FM4.5	12	4.5							1.45
6FM5	12	5.0							1.52
6FM4.2	12	4.2	195	47	70	76	F1	6	1.42
6FM5A	12	5.0	140	48	102	103	+F2-F1	6	1.60
6FM5A	12	5.0	151	65	94	100	F1/F2	1	1.7
6FM5.0S	12	5.0	151	65	94	100	F1/F2	1	1.75
6FM5.5S	12	5.5	151	65	94	100	F1/F2	1	1.9
6FM6.5	12	6.5	151	65	94	100	F1/F2	1	1.98
6FM6.8	12	6.8	151	65	94	100	F1/F2	1	2.00
6FM7E	12	7.0	151	65	94	100	F1/F2	1	2.05
6FM7	12	7.0	151	65	94	100	F1/F2	1	2.1
6FM7A	12	7.0	151	65	94	100	F1/F2	1	2.15
6FM7.2	12	7.2	151	65	94	100	F1/F2	1	2.20
6FM7.2A	12	7.2	151	65	94	100	F1/F2	1	2.25
6FM7.5	12	7.5	151	65	94	100	F1/F2	1	2.30
6FM8.5	12	8.5	151	65	94	100	F1/F2	1	2.43
6FM9	12	9.0	151	65	94	100	F1/F2	1	2.50
6FM9A	12	9.0	151	65	94	100	F1/F2	1	2.60
6FM10	12	10.0	151	65	111	117	F2/F1	1	2.80
6FM10A	12	10.0	151	98	95	101	F2/F1	1	3.05
6FM10S	12	10.0	181	77	167	167	F17/F18	3	3.1
6FM10L	12	10.0	181	77	117	117	F2/F17	1	3.30
6FM10H	12	10.0	151	98	95	101	F2/F1	1	3.30
6FM12	12	12.0	151	98	95	101	F2/F1	1	3.45
6FM12H	12	12.0	151	98	95	101	F2/F1	1	3.60
6FM15	12	15.0	181	77	167	167	F17/F18	3	4.8
6FM17	12	17.0							5.1
6FM18	12	18.0							5.25
6FM20	12	20.0							5.7
6FM20S	12	20.0	181	78	172	172	M5	3	6.5
6FM24	12	24.0	166	175	125	125	F17/F18	3	7.6
6FM24S	12	24.0							7.35
6FM26	12	26.0							7.8
6FM28	12	28.0							8.2
6FM24	12	24.0	165	125	175	182/175	F18	3	7.5
6FM28A	12	28.0	165	125	175	182/175	F18	3	8.6
