Solar UPS inverter system 12v7.5ah deep cycle solar gel lead acid battery

Description:

Place of Origin:

Guangdong, China (Mainland)

Brand Name:

CHAMPION

Model Number:

6FM7.5G

Usage:

UPS,SOLAR,INVERTER

Voltage:

12v

Sealed Type:

Sealed

Maintenance Type:

Free

Size:

151*65*94*99mm

Weight:

2.4kg

Nominal Capacity:

7.5Ah

Material:

ABS granule

Certificate:

UL, CE Approved

Application:

Emergency Lighting,Spotlights, Fire & Security Alarm, Solar Power

Characteristics:

Long service life, Good deep charge cycle performance

Warranty time:

2 Year

UPS Battery Contruction:

• Container/Cover: Made of  ABS Plastic raw mateial

• Negative Plates:Use the special PbCa alloy grids, optimize the recombination efficiency and less gassing.

• Separator:Import high quality AGM separator.

• Positive Plates: PbCa grids minimize corrosion and prolong life.

• Terminal post: Cooper material with maximum conductivity, enhance the high current rapidly.

• Vent Valve: Allows the release of excess gas automatically for safety.

12v 7.5ah Sealed Lead Acid long life Battery Applications:

• UPS&Solar system

• Telecommunication

• Banks & Financial Centre

• Hospital& Testing Laboratories

• Power Generation Plants

• Emergency Lighting

• Alarm system

• High Power Backup Supply

UPS Battery Feature:

• Stable quality&high reliability

• Sealed construction

• Environmentally friendly

• Maintenance-free operation

• Low pressure venting system

• Heavy duty grid

• Low self discharge

Specifications:

Model	Voltage	Capacity	Dimensions				Weight ± 2% kg
			Length	Width	Height	Total Height
	(V)	(AH)	mm	mm	mm	mm	kg
6FM7G	12	7	151	65	94	100	2.25
6FM7.2G	12	7	151	65	94	100	2.35
6FM7.5G	12	7	151	65	94	100	2.4
6FM9G	12	7	151	65	94	100	2.6
6FM12G	12	12	151	98	95	101	3.8
6FM18G	12	18	181	77	167	167	5.45
6FM24G	12	24	166	175	125	125	7.9
6FM28G	12	28					8.7
3FM200G	6	200	321	176	226	229	32
6FM40G	12	40	197	165	170	170	13.5
6FM45G	12	45	197	165	170	170	14.5
6FM50G	12	50	229	138	208	211	17.8
6FM55G	12	55					19
6FM50GA	12	50	258	133	200	200	16.5
6FM65G	12	65	350	167	179	186	22.5
6FM60G	12	60	260	168	211	214	21
6FM70G	12	70					23.7
6M80G	12	80					25.5
6FM90G	12	90	306	169	211	214	28.5
6FM100G	12	100	330	171	214	220	32
6FM120G	12	120	409	176	225	225	37
6FM150G	12	150	485	172	240	240	46
6FM200G	12	200	522	238	218	221	65
6FM25G	12	250	521	269	220	223	78

Competitive Advantage:

Capable of high discharge rates

Best cost performance products

First class ABS container

Top lead of purity 99.994%

Low self-discharge

Long service life

Manufacture with more than 15 years history
