Solar Ups Inverter Led Lamp Power 9ah 12v Deep Cycle Gel Battery
Long life gel lead acid battery solar ups inverter led lamp power 12v9ah battery
Description:
Quick Details
| Place of Origin: | Guangdong, China (Mainland) | Brand Name: | CHAMPION | Model Number: | 6FM9G |
| Usage: | UPS, backup power supply | Voltage: | 12v | Sealed Type: | Sealed |
| Maintenance Type: | Free | Size: | 151*65*94mm | Weight: | 2.5kg |
| Nominal Capacity: | 9AH | Warranty: | 13 Months | Color: | Black, green or other for option |
| OEM: | Available | Container Material: | ABS | Certificates: | CE/ROHS |
Applications:
1)Communication Systems: Switch, Microwave Stations, Mobile Base Stations, Data Centers, Radio and Broadcasting Stations.
2)Motivity Field: Robots, Electric Toys, Electric Tools & Portable Vacuum Cleaners
3)Solar & Wind Power Generation Systems
4)Signal System & Emergency Lighting Systems
5)EPS & UPS Systems
Specification:
Product Name | 12v 9ah battery | |
Capacity | 20HR(10.5V) | 9Ah |
10HR(10.5V) | 8.4Ah | |
1HR(9.60V) | 5.8Ah | |
| Length | 151±1.5mm (5.94inch) |
Width | 65±1mm (2.56inch) | |
Height | 94±1mm (3.70inch) | |
Total Height | 100±1mm (3.94inch) | |
Approx. Weight | 2.5kg | |
Terminal type | F1/F2 | |
Internal resistance | Approx. 19mΩ | |
| 40°C | 102% |
25°C | 100% | |
0°C | 85% | |
-15°C | 65% | |
| 3 month | Remaining Capacity: 91% |
6 month | Remaining Capacity: 82% | |
12 month | Remaining Capacity: 65% | |
Nominal operating | 25°C±3°C(77°F±5°F) | |
Operating temperature range | Discharge | -15°C~50°C(5°F~122°F) |
Charge | -10°C~50°C(14°F~122°F) | |
Storage | -20°C~50°C(-4°F~122°F) | |
| 13.60 to 13.80V | |
| 14.50 to 14.90V | |
Maximum charging current | 2.7A | |
Terminal material | Copper | |
Maximum discharge current | 135A(5 sec.) | |
Designed floating life(20°C) | 3~5 years | |
Competitive Advantage:
- Sealed and maintenance free, safety, no leakage
- ABS containers and covers optional
- With safety valve
- Made by No 8 largest battery factory in China
- High quality and reliability
- Exceptional deep discharge recovery
- Flexible design for multiple installation
- Wide operating temp. range
- High capability, high energy density
- Long service life
- Excellent safety, discharging, shock-proof and impact proof performance
- Good resistance to overdischarge, overcharge and high current
