Good Cyclic Property Sealed Lead Acid Battery For UPS / Inverter / Solar System
Good Cyclic Property Sealed Lead Acid Battery For UPS / Inverter / Solar System
Sealed Lead Acid Battery Description:
- Good cyclic property. Enhanced overcharge endurance and over discharge recovery property
- High purity raw material: ensure low self discharge rate
- Using oxygen recombination technology: maintenance-free
- Lower acid density, excess of electrolyte and larger distance between plates to keep battery at low
temperature and slow down plate grid corrosion speed - ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)
- Unique plate group configuration, high quality AGM separator and battery management system ensure battery with a longer service life
- Special vent valve design: control water losing, prevent air and spark going inside
Sealed Lead Acid Battery Specifications:
| 12V Batteries | |||||||||
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | Position | (Kg±5%) | |
| 6FM0.8 | 12 | 0.8 | 96 | 25 | 62 | 62 | AMP | 0.34 | |
| 6FM1.2 | 12 | 1.2 | 97 | 43 | 52 | 58 | F1 | 2 | 0.55 |
| 6FM2 | 12 | 2.0 | 178 | 35 | 61 | 67 | F1 | 6 | 0.80 |
| 6FM2.2 | 12 | 2.2 | 178 | 35 | 61 | 67 | F1 | 6 | 0.83 |
| 6FM2.3 | 12 | 2.3 | 178 | 35 | 61 | 67 | F1 | 6 | 0.90 |
| 6FM2E | 12 | 2.0 | 70 | 48 | 98 | 104 | F1 | 6 | 0.75 |
| 6FM2.3E | 12 | 2.3 | 0.80 | ||||||
| 6FM2.6 | 12 | 2.6 | 0.85 | ||||||
| 6FM2.5 | 12 | 2.5 | 104 | 48 | 70 | 70 | +F2-F1 | 2 | 0.90 |
| 6FM2.8B | 12 | 2.8 | 0.98 | ||||||
| 6FM2.8 | 12 | 2.8 | 67 | 67 | 97 | 103 | F1 | 6 | 1.00 |
| 6FM2.8A | 12 | 2.8 | 132 | 33 | 98 | 104 | F1 | 6 | 1.00 |
| 6FM2.9 | 12 | 2.9 | 79 | 56 | 99 | 105 | F1 | 3 | 1.05 |
| 6FM3.2 | 12 | 3.2 | 134 | 67 | 61 | 67 | F1 | 2 | 1.25 |
| 6FM4 | 12 | 4.0 | 90 | 70 | 101 | 107 | F1/F2 | 6 | 1.36 |
| 6FM3.6 | 12 | 3.6 | 1.25 | ||||||
| 6FM4.5 | 12 | 4.5 | 1.45 | ||||||
| 6FM5 | 12 | 5.0 | 1.52 | ||||||
| 6FM4.2 | 12 | 4.2 | 195 | 47 | 70 | 76 | F1 | 6 | 1.42 |
| 6FM5A | 12 | 5.0 | 140 | 48 | 102 | 103 | +F2-F1 | 6 | 1.60 |
| 6FM5A | 12 | 5.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.7 |
| 6FM5.0S | 12 | 5.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.75 |
| 6FM5.5S | 12 | 5.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.9 |
| 6FM6.5 | 12 | 6.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.98 |
| 6FM6.8 | 12 | 6.8 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.00 |
| 6FM7E | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.05 |
| 6FM7 | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.1 |
| 6FM7A | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.15 |
| 6FM7.2 | 12 | 7.2 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.20 |
| 6FM7.2A | 12 | 7.2 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.25 |
| 6FM7.5 | 12 | 7.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.30 |
| 6FM8.5 | 12 | 8.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.43 |
| 6FM9 | 12 | 9.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.50 |
| 6FM9A | 12 | 9.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.60 |
| 6FM10 | 12 | 10.0 | 151 | 65 | 111 | 117 | F2/F1 | 1 | 2.80 |
| 6FM10A | 12 | 10.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.05 |
| 6FM10S | 12 | 10.0 | 181 | 77 | 167 | 167 | F17/F18 | 3 | 3.1 |
| 6FM10L | 12 | 10.0 | 181 | 77 | 117 | 117 | F2/F17 | 1 | 3.30 |
| 6FM10H | 12 | 10.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.30 |
| 6FM12 | 12 | 12.0 | F2/F1 | 1 | 3.45 | ||||
| 6FM12H | 12 | 12.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.60 |
| 6FM15 | 12 | 15.0 | 181 | 77 | 167 | 167 | F17/F18 | 3 | 4.8 |
| 6FM17 | 12 | 17.0 | 5.1 | ||||||
| 6FM18 | 12 | 18.0 | 5.25 | ||||||
| 6FM20 | 12 | 20.0 | 5.7 | ||||||
| 6FM20S | 12 | 20.0 | 181 | 78 | 172 | 172 | M5 | 3 | 6.5 |
| 6FM24 | 12 | 24.0 | 166 | 175 | 125 | 125 | F17/F18 | 3 | 7.6 |
| 6FM24S | 12 | 24.0 | 7.35 | ||||||
| 6FM26 | 12 | 26.0 | 7.8 | ||||||
| 6FM28 | 12 | 28.0 | 8.2 | ||||||
| 6FM24 | 12 | 24.0 | 165 | 125 | 175 | 182/175 | F18 | 3 | 7.5 |
| 6FM28A | 12 | 28.0 | 8.6 | ||||||
| 6FM31 | 12 | 31 | 195 | 130 | 155 | 166 | M6 | 6 | 9.6 |
| 6FM33 | 12 | 33 | 10 | ||||||
| 6FM35 | 12 | 35 | 10.5 | ||||||
| 6FM38 | 12 | 38 | 197 | 165 | 170 | 170 | M6 | 3 | 12 |
| 6FM40 | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 3 | 12.5 |
| 6FM40H | 12 | 41 | 197 | 165 | 170 | 170 | M6 | 3 | 13 |
| 6FM42 | 12 | 42 | 197 | 165 | 170 | 170 | M6 | 3 | 13.5 |
| 6FM45 | 12 | 45 | 197 | 165 | 170 | 170 | M6 | 3 | 14 |
| 6FM50 | 12 | 50 | 229 | 138 | 211 | 214 | M6 | 6 | 15.5 |
| 6FM55 | 12 | 55 | M6 | 16.5 | |||||
| 6FM50A | 12 | 50 | 229 | 138 | 205 | 210 | M6 | 6 | 15.5 |
| 6FM110B | 12 | 110 | 330 | 171 | 214 | 220 | M8 | 6 | 33 |
| 6FM120A | 12 | 120 | 409 | 176 | 225 | 225 | M8 | 6 | 34 |
| 6FM90S | 12 | 90 | 406 | 173 | 208 | 238 | M8 | 6 | 28 |
| 6FM110S | 12 | 110 | 32 | ||||||
| 6FM120 | 12 | 120 | 33 | ||||||
| 6FM120B | 12 | 120 | 280 | 265 | 207 | 227 | M8 | 6 | 37.5 |
| 6FM110A | 12 | 110 | 280 | 265 | 207 | 227 | M8 | 6 | 35.5 |
| 6FM140 | 12 | 140 | 280 | 265 | 207 | 227 | M8 | 6 | 39.5 |
| 6FM130 | 12 | 130 | 280 | 265 | 207 | 227 | M8 | 6 | 37.5 |
| 6FM134 | 12 | 135 | 340 | 172 | 282 | 284 | M8 | 6 | 42 |
| 6FM110SS | 12 | 110 | 485 | 172 | 240 | 240 | M8 | 6 | 35 |
| 6FM135S | 12 | 135 | 485 | 172 | 240 | 240 | M8 | 6 | 42 |
| 6FM150 | 12 | 150 | 485 | 172 | 240 | 240 | M8 | 6 | 43 |
| 6FM150S | 12 | 150 | 530 | 207 | 210 | 213 | M8 | 2 | 46.5 |
| 6FM160 | 12 | 160 | 530 | 207 | 210 | 213 | M8 | 2 | 47.5 |
| 6FM180 | 12 | 180 | 52.5 | ||||||
| 6FM135SS | 12 | 135 | 522 | 238 | 218 | 221 | M8 | 2 | 49 |
| 6FM160S | 12 | 160 | 522 | 238 | 218 | 221 | M8 | 2 | 47.5 |
| 6FM180S | 12 | 180 | 522 | 238 | 218 | 221 | M8 | 2 | 56 |
| 6FM190S | 12 | 190 | 57.5 | ||||||
| 6FM200 | 12 | 200 | 60 | ||||||
| 6FM220 | 12 | 220 | 522 | 238 | 218 | 221 | M8 | 2 | 62 |
| 6FM225 | 12 | 225 | 522 | 238 | 218 | 221 | M8 | 2 | 63 |
| 6FM240S | 12 | 240 | 521 | 269 | 220 | 223 | M8 | 2 | 65 |
| 6FM250 | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 71 |
| 6FM250A | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 71 |
| 6FM250E | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 69.5 |
About US
Champion Storage Battery Company Limited,was founded in year 2000, the leading VRLA battery manufacturer in the world, with an area of 180,000 square meters and 1000 employee, Champion's produce capacity equals to 1 million pieces of 12v7ah per month.
Champion become rank 8th among 1500 Sealed Lead Acid (SLA) Battery manufacturers & exporters in China by year 2014. with it headquarters based in Shenzhen and factories located in Jiangmen and Shaoguan 2 cities ,Guangdong Province China, which gains the geographic and economic advantages for doing international business. Besides, Champion Battery has its own plate- fabrication facilities to provide one-stop OEM service for customers in speedy lead-time. With a combination of professional management and engineering teams, advanced machineries, a cost-effective production and a healthy financial condition, Champion Battery has all the essential qualities to be a leading SLA battery manufacturer worldwide.
Sealed Lead Acid Battery Details
