ABS Plastic Cover Sealed Lead Acid Battery With Long Service Life
ABS Plastic Cover Sealed Lead Acid Battery With Long Service Life
Sealed Lead Acid Battery Description:
1) Maintenance-Free Operation
Absorbent Glass Mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance. During the expected float service life of batteries, no need to check the specific gravity of the electrolyte or add water.
2) Good Discharging Ability
Tight assembly technology ensures an excellent high-rate discharge performance.
3) Long Service Life
A unique corrosion-resistant grid alloy ensures batteries have long service life.
Sealed Lead Acid Battery Feature:
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
Sealed Lead Acid Battery Application:
1. Solar and wind energy storage system
2. EPS and UPS battery backup
3. Signal system , emergency lighting system , security system
4. Telecommunication Equipment
5. Power plant and transmission system
Sealed Lead Acid Battery Specifications:
| 12V Batteries | |||||||||
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Terminal | Weight | |||
| V | (Ah) | L | W | H | TH | Type | Position | (Kg±5%) | |
| 6FM0.8 | 12 | 0.8 | 96 | 25 | 62 | 62 | AMP | 0.34 | |
| 6FM1.2 | 12 | 1.2 | 97 | 43 | 52 | 58 | F1 | 2 | 0.55 |
| 6FM2 | 12 | 2.0 | 178 | 35 | 61 | 67 | F1 | 6 | 0.80 |
| 6FM2.2 | 12 | 2.2 | 178 | 35 | 61 | 67 | F1 | 6 | 0.83 |
| 6FM2.3 | 12 | 2.3 | 178 | 35 | 61 | 67 | F1 | 6 | 0.90 |
| 6FM2E | 12 | 2.0 | 70 | 48 | 98 | 104 | F1 | 6 | 0.75 |
| 6FM2.3E | 12 | 2.3 | 0.80 | ||||||
| 6FM2.6 | 12 | 2.6 | 0.85 | ||||||
| 6FM2.5 | 12 | 2.5 | 104 | 48 | 70 | 70 | +F2-F1 | 2 | 0.90 |
| 6FM2.8B | 12 | 2.8 | 0.98 | ||||||
| 6FM2.8 | 12 | 2.8 | 67 | 67 | 97 | 103 | F1 | 6 | 1.00 |
| 6FM2.8A | 12 | 2.8 | 132 | 33 | 98 | 104 | F1 | 6 | 1.00 |
| 6FM2.9 | 12 | 2.9 | 79 | 56 | 99 | 105 | F1 | 3 | 1.05 |
| 6FM3.2 | 12 | 3.2 | 134 | 67 | 61 | 67 | F1 | 2 | 1.25 |
| 6FM4 | 12 | 4.0 | 90 | 70 | 101 | 107 | F1/F2 | 6 | 1.36 |
| 6FM3.6 | 12 | 3.6 | 1.25 | ||||||
| 6FM4.5 | 12 | 4.5 | 1.45 | ||||||
| 6FM5 | 12 | 5.0 | 1.52 | ||||||
| 6FM4.2 | 12 | 4.2 | 195 | 47 | 70 | 76 | F1 | 6 | 1.42 |
| 6FM5A | 12 | 5.0 | 140 | 48 | 102 | 103 | +F2-F1 | 6 | 1.60 |
| 6FM5A | 12 | 5.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.7 |
| 6FM5.0S | 12 | 5.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.75 |
| 6FM5.5S | 12 | 5.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.9 |
| 6FM6.5 | 12 | 6.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 1.98 |
| 6FM6.8 | 12 | 6.8 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.00 |
| 6FM7E | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.05 |
| 6FM7 | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.1 |
| 6FM7A | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.15 |
| 6FM7.2 | 12 | 7.2 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.20 |
| 6FM7.2A | 12 | 7.2 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.25 |
| 6FM7.5 | 12 | 7.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.30 |
| 6FM8.5 | 12 | 8.5 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.43 |
| 6FM9 | 12 | 9.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.50 |
Competitive Advantage:
1> Sealed, maintenance free.
2> Design life: 15 years (floating charge).
3> Reliably Sealed and Leakproof Construction.
4> ABS(V0 optional) container materials.
