Tight Assembly Regulated Gel Lead Acid Battery With Strong Heat Dissipation
Tight Assembly Regulated Gel Lead Acid Battery With Strong Heat Dissipation
Gel Lead Acid Battery Introduction
. Gel type suitable for deep cycle use
. Prevalling design in consturction
. Much more energy in comparison to the battery with the same rated capacity
. Front access terminals for easy and quick connection
Gel Lead Acid Battery Application.
UPS, Broadband, Electric powered vehicles, Electric powered toys, Vacuum cleaners, Medical Equipment, Goof cars and buggies, Wheel chairs, PVs, solar systems, control systems, power systems, wind energy systems, telecommunication /communication systems & etc.
Gel Lead Acid Battery Specifications:
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | (Kg±2%) | |
| 3FM100G | 6 | 100 | 194 | 170 | 205 | 210 | M8 | 15.5 |
| 3FM150G | 6 | 150 | 260 | 180 | 245 | 250 | M8 | 23 |
| 3FM180G | 6 | 180 | 307 | 169 | 220 | 225 | M8 | 27 |
| 3FM200G | 6 | 200 | 321 | 176 | 226 | 229 | M8 | 29.5 |
| 3FM300G | 6 | 300 | 295 | 178 | 345 | 348 | M8 | 47 |
| 4FM180G | 8 | 180 | 260 | 182 | 295 | 298 | M8 | 36.5 |
| 6FM33G | 12 | 33 | 195 | 130 | 155 | 166 | M6 | 10 |
| 6FM40G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 12.5 |
| 6FM42G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 13.5 |
| 6FM50G | 12 | 50 | 229 | 138 | 211 | 214 | M6 | 15.5 |
| 6FM55G | 12 | 50 | 229 | 138 | 205 | 210 | M6 | 16.5 |
| 6FM70G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 21.5 |
| 6FM75G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 22.5 |
| 6FM60G | 12 | 65 | 350 | 167 | 179 | 179 | M6 | 19.5 |
| 6FM65G | 12 | 65 | 350 | 167 | 179 | 179 | M6 | 20.5 |
| 6FM90G | 12 | 90 | 306 | 169 | 211 | 214 | M6 | 27 |
| 6FM100G | 12 | 100 | 330 | 171 | 214 | 220 | M8 | 30 |
| 6FM120G | 12 | 120 | 406 | 173 | 208 | 238 | M8 | 34 |
| 6FM134G | 12 | 120 | 340 | 172 | 282 | 284 | M8 | 42 |
| 6FM140G | 12 | 120 | 340 | 172 | 282 | 284 | M8 | 42.5 |
| 6FM150G | 12 | 150 | 485 | 172 | 240 | 240 | M8 | 43 |
| 6FM160G | 12 | 160 | 530 | 207 | 210 | 213 | M8 | 47.5 |
| GFM300G | 2 | 300 | 171 | 151 | 330 | 364 | M8 | 18 |
| GFM400G | 2 | 400 | 210 | 175 | 330 | 367 | M8 | 25 |
| GFM500G | 2 | 500 | 241 | 175 | 330 | 365 | M8 | 30 |
| GFM600G | 2 | 600 | 302 | 175 | 330 | 367 | M8 | 36 |
| GFM800G | 2 | 800 | 410 | 175 | 330 | 367 | M8 | 50 |
| GFM1000G | 2 | 1000 | 475 | 175 | 330 | 367 | M8 | 60 |
| GFM1500G | 2 | 1500 | 400 | 350 | 345 | 382 | M8 | 93 |
| GFM2000G | 2 | 2000 | 490 | 350 | 345 | 382 | M8 | 120 |
| GFM3000G | 2 | 3000 | 710 | 350 | 345 | 382 | M8 | 180 |
Competitive Advantage:
Capable of high discharge rates
Special grid and design technology
Manufacture with more than 15 years history
Special container size for more convenient installation
Best performance with low cost
Low self-discharge
