F187 Sealed Deep Cycle Battery / Advanced Lead Acid Ups Vrla Battery
F187 Sealed Deep Cycle Battery / Advanced Lead Acid Ups Vrla Battery
Sealed Deep Cycle Battery Applications:
1. Portable measuring and medical electronic instruments
2. Battery powered wheelchairs
3. Fire and security alarm systems
4. Ups/Eps power supply
5. Powers tools
6. Medical equipments
7. Electric tools and electric toys
8. Television and video recorders
Sealed Deep Cycle Battery Description:
| Place of Origin: |
Guangdong, China (Mainland)
|
Brand Name: | CHAMPION | Model Number: |
6v 5ah
|
| Usage: |
emergency light
|
Voltage: |
6V
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
70*47*101*106mm
|
Weight: |
0.76kg
|
| Nominal Capacity: |
5ah/20hr
|
Company established year: |
2000
|
Certificate: |
ISO,CE,UL
|
| Cycle use: |
7.30-7.50V
|
Standby use: |
6.75-6.90V
|
Initial current: |
Less than 1.4A
|
Specifications:
|
Nominal Voltage |
6V |
||
|
Nominal Capacity (20 hour rate) |
5Ah |
||
|
Capacity 25°C(77°F) |
20 hour rate (0.225A) |
5Ah |
|
|
10 hour rate (0.427A) |
4.55Ah |
||
|
5 hour rate (0.72A) |
3.9Ah |
||
|
1 hour rate (2.93A) |
2.99Ah |
||
|
Internal Resistance |
Full Charged Battery 25°C(77°F) |
≤28mΩ |
|
|
Cyclic Life |
50%(C20) Depth of discharge |
600Times |
|
|
Float Life |
25°C(77°F) Float charge at 6.9V |
About 5 Years |
|
|
Capacity affected by Temperature (20 hour ) |
40°C (104°F) |
102% |
|
|
25°C (77°F) |
100% |
||
|
0°C (32°F) |
85% |
||
|
-15°C (5°F) |
65% |
||
|
Self-Discharge 25°C(77°F) |
Capacity after 3 month storage |
90% |
|
|
Capacity after 6 month storage |
80% |
||
|
Capacity after 12 month storage |
62% |
||
|
Charge (Constant Voltage) 25°C(77°F) |
Cycle |
Initial Charging Current Less than 1.4A Voltage 7.30-7.50V |
|
|
Float |
Voltage 6.75-6.90V |
||
Competitive Advantage:
1. Stable quality and High Reliability .
2. Sealed, maintenance free.
3. Low self-discharge, less than 3% of capacity per month at 25°C.
4. Wide Operating Environment
5. Long cycle life: above 300 cycles at 80% DOD term.
6. ABS(VO optional) container materials.
7. Reliably Sealed and Leakproof Construction.
8. Design life: 6 years (floating charge).
9. High reliability, CE, UL and ISO certified.
10. Stable quality and High Reliability .
