Sulfuric Lead Acid Deep Cycle Battery , Solar Power Lead Acid Solar Batteries
Sulfuric Lead Acid Deep Cycle Battery , Solar Power Lead Acid Solar Batteries
Lead Acid Deep Cycle Battery Applications :
♦Solar and wind energy storage system
♦EPS and UPS battery backup
♦Signal system , emergency lighting system , security system
♦Telecommunication Equipment
♦Power plant and transmission system
Lead Acid Deep Cycle BatterySpecifications:
| Product Name |
12v 5ah battery |
||
|
Capacity (25°C) |
20HR(10.5V) |
4Ah |
|
|
10HR(10.5V) |
3.7Ah |
||
|
1HR(9.60V) |
2.25Ah |
||
|
Dimension |
Length |
90±1mm (3.54inch) |
|
|
Width |
70±1mm (2.76inch) |
||
|
Height |
101±1mm (3.98inch) |
||
|
Total Height |
107±1mm (4.21inch) |
||
|
Approx. Weight |
1.45kg |
||
|
Terminal type |
F1/F2 |
||
|
Internal resistance (Fully charged, 25°C) |
Approx. 26mΩ |
||
|
Capacity affected by temperature (20HR) |
40°C |
102% |
|
|
25°C |
100% |
||
|
0°C |
85% |
||
|
-15°C |
65% |
||
|
Self-discharge (25°C) |
3 month |
Remaining Capacity: 91% |
|
|
6 month |
Remaining Capacity: 82% |
||
|
12 month |
Remaining Capacity: 65% |
||
|
Nominal operating temperature |
25°C±3°C(77°F±5°F) |
||
|
Operating temperature range |
Discharge |
-15°C~50°C(5°F~122°F) |
|
|
Charge |
-10°C~50°C(14°F~122°F) |
||
|
Storage |
-20°C~50°C(-4°F~122°F) |
||
|
Float charging voltage(25°C) |
13.60 to 13.80V Temperature compensation: -18mV/°C |
||
|
Cyclic charging voltage(25°C) |
14.50 to 14.90V Temperature compensation: -30mV/°C |
||
|
Maximum charging current |
1.5A |
||
|
Terminal material |
Copper |
||
|
Maximum discharge current |
75A(5 sec.) |
||
|
Designed floating life(20°C) |
3~5 years |
||
Lead Acid Deep Cycle Battery Competitive Advantage:
- With safety valve
- High quality and reliability
- Exceptional deep discharge recovery
- Flexible design for multiple installation
- Wide operating temp. range
- High capability, high energy density
- Long service life
-
Excellent safety, discharging, shock-proof and impact proof performance
- Good resistance to overdischarge, overcharge and high current
- Made by shenzhen battery factory
During the expected float service life of CHAMPION batteries, there is no need to check the specific gravity of the electrolyte, or add water. In fact, there is no provision for these maintenance functions.
