Sulfuric Sealed Lead Acid Battery 12v / Rechargeable Lead Acid Battery
Sulfuric Sealed Lead Acid Battery 12v / Rechargeable Lead Acid Battery
Sealed Lead Acid Battery 12v Applications:
| 1. Green energy systems (solar, wind, hydro, etc) | 2. Solar power stations | 3. Pump systems |
| 4. Telecommunications installations | 5. Measurement stations | 6. Boats or buoys |
| 7. Signal station | 8. Survey and Mapping system | 9. Emergency lighting |
| 10. Caravans | 11. Traffic lights | 12. Street lightening |
| 13. Lawn lamp | 14. Street signs | 15. SOS pillars |
| 17. Alarm installations | 18. Weekend cottage camping |
Sealed Lead Acid Battery 12v Specifications:
Nominal Voltage | 12V | ||
Nominal Capacity (10 hour rate) | 90Ah | ||
Capacity | 10 hour rate (12A) | 90Ah | |
3 hour rate (30A) | 60Ah | ||
1 hour rate (66A) | 36Ah | ||
Internal Resistance | Full Charged Battery 25°C(77°F) | ≤10mΩ | |
Cyclic Life | 50%(C10) Depth of discharge | 600Times | |
Float Life | 25°C(77°F) Float charge at 13.8V | About 10 Years | |
Capacity affected by Temperature | 40°C (104°F) | 102% | |
25°C (77°F) | 100% | ||
0°C (32°F) | 85% | ||
-15°C (5°F) | 65% | ||
Self-Discharge | Capacity after 3 month storage | 90% | |
Capacity after 6 month storage | 80% | ||
Capacity after 12 month storage | 62% | ||
Charge (Constant Voltage) 25°C(77°F) | Cycle | Initial Charging Current Less than 36A | |
Float | Voltage 13.5-13.8V | ||
| 6FM31 | 12 | 31 | 195 | 130 | 155 | 166 | M6 | 6 | 9.6 |
| 6FM33 | 12 | 33 | 10 | ||||||
| 6FM35 | 12 | 35 | 10.5 | ||||||
| 6FM38 | 12 | 38 | 197 | 165 | 170 | 170 | M6 | 3 | 12 |
| 6FM40 | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 3 | 12.5 |
| 6FM40H | 12 | 41 | 197 | 165 | 170 | 170 | M6 | 3 | 13 |
| 6FM42 | 12 | 42 | 197 | 165 | 170 | 170 | M6 | 3 | 13.5 |
| 6FM45 | 12 | 45 | 197 | 165 | 170 | 170 | M6 | 3 | 14 |
| 6FM50 | 12 | 50 | 229 | 138 | 211 | 214 | M6 | 6 | 15.5 |
| 6FM55 | 12 | 55 | M6 | 16.5 | |||||
| 6FM50A | 12 | 50 | 229 | 138 | 205 | 210 | M6 | 6 | 15.5 |
| 6FM60 | 12 | 60 | 260 | 168 | 211 | 214 | M6 | 6 | 19 |
| 6FM60E | 12 | 60 | 260 | 168 | 211 | 214 | M6 | 6 | 18.8 |
| 6FM70 | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 6 | 21.5 |
| 6FM75 | 12 | 75 | 260 | 168 | 211 | 214 | M6 | 6 | 22.5 |
| 6FM80 | 12 | 80 | 260 | 168 | 211 | 214 | M6 | 6 | 23 |
| 6FM65 | 12 | 65 | 350 | 167 | 179 | 179 | M6 | 6 | 20 |
| 6FM80A | 12 | 80 | 350 | 167 | 179 | 179 | M6 | 6 | 22 |
| 6FM90E | 12 | 90 | 306 | 169 | 211 | 214 | M6 | 6 | 26.5 |
| 6FM95 | 12 | 95 | 306 | 169 | 211 | 214 | M6 | 6 | 27 |
| 6FM80S | 12 | 80 | 330 | 171 | 214 | 220 | M6 | 6 | 26 |
| 6FM90A | 12 | 90 | 330 | 171 | 214 | 220 | M6 | 6 | 27.3 |
| 6FM70S | 12 | 90 | 330 | 171 | 214 | 220 | M6 | 6 | 24.5 |
| 6FM90A | 12 | 90 | 330 | 171 | 214 | 220 | M6 | 27.5 | |
| 6FM90B | 12 | 90 | 330 | 171 | 214 | 220 | M6 | 6 | 28 |
| 6FM100E | 12 | 100 | 330 | 171 | 214 | 220 | M8 | 6 | 29 |
| 6FM100 | 12 | 100 | 330 | 171 | 214 | 220 | M8 | 6 | 30 |
| 6FM110 | 12 | 110 | 330 | 171 | 214 | 220 | M8 | 6 | 32 |
| 6FM110B | 12 | 110 | 330 | 171 | 214 | 220 | M8 | 6 | 33 |
| 6FM120A | 12 | 120 | 409 | 176 | 225 | 225 | M8 | 6 | 34 |
| 6FM90S | 12 | 90 | 406 | 173 | 208 | 238 | M8 | 6 | 28 |
| 6FM110S | 12 | 110 | 32 | ||||||
| 6FM120 | 12 | 120 | 33 | ||||||
| 6FM120B | 12 | 120 | 280 | 265 | 207 | 227 | M8 | 6 | 37.5 |
| 6FM110A | 12 | 110 | 280 | 265 | 207 | 227 | M8 | 6 | 35.5 |
| 6FM140 | 12 | 140 | 280 | 265 | 207 | 227 | M8 | 6 | 39.5 |
| 6FM130 | 12 | 130 | 280 | 265 | 207 | 227 | M8 | 6 | 37.5 |
| 6FM134 | 12 | 135 | 340 | 172 | 282 | 284 | M8 | 6 | 42 |
| 6FM110SS | 12 | 110 | 485 | 172 | 240 | 240 | M8 | 6 | 35 |
| 6FM135S | 12 | 135 | 485 | 172 | 240 | 240 | M8 | 6 | 42 |
| 6FM150 | 12 | 150 | 485 | 172 | 240 | 240 | M8 | 6 | 43 |
| 6FM150S | 12 | 150 | 530 | 207 | 210 | 213 | M8 | 2 | 46.5 |
| 6FM160 | 12 | 160 | 530 | 207 | 210 | 213 | M8 | 2 | 47.5 |
| 6FM180 | 12 | 180 | 52.5 | ||||||
| 6FM135SS | 12 | 135 | 522 | 238 | 218 | 221 | M8 | 2 | 49 |
| 6FM160S | 12 | 160 | 522 | 238 | 218 | 221 | M8 | 2 | 47.5 |
| 6FM180S | 12 | 180 | 522 | 238 | 218 | 221 | M8 | 2 | 56 |
| 6FM190S | 12 | 190 | 57.5 | ||||||
| 6FM200 | 12 | 200 | 60 | ||||||
| 6FM220 | 12 | 220 | 522 | 238 | 218 | 221 | M8 | 2 | 62 |
| 6FM225 | 12 | 225 | 522 | 238 | 218 | 221 | M8 | 2 | 63 |
| 6FM240S | 12 | 240 | 521 | 269 | 220 | 223 | M8 | 2 | 65 |
| 6FM250 | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 71 |
| 6FM250A | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 71 |
| 6FM250E | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 2 | 69.5 |
Competitive Advantage:
- Ideal for cyclic uses
- Good tolerance to higher temperature applications.
- ABS containers and covers(UL94HB, UL94V-0) optional.
- Safety valve installation for explosion proof.
- Higher safety & reliable construction.
